WAGO 232135 5-pole Female Header
The WAGO 232-135 is a robust 5-pole female header ideal for a wide range of industrial applications, including board-to-board and board-to-wire connections. Its straight design and 5mm pin spacing facilitate easy integration into PCB layouts. The header offers touch-proof PCB outputs for enhanced safety and incorporates coding fingers for reliable mating. It is designed for horizontal or vertical PCB mounting and is compliant with numerous industry standards including UL, CSA, and KEMA, ensuring reliable performance in demanding environments. The header's polyamide 66 (PA 66) insulating material and tin-plated copper alloy contacts contribute to its durability and long-term reliability.
WAGO 232135 5-pole Female Header Specifications:
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- No. of poles: 5
- Total number of potentials: 5
- Number of connection types: 1
- Number of levels: 1
- Pin spacing: 5 mm / 0.197 inch
- Width: 26.5 mm / 1.043 inch
- Height: 23.25 mm / 0.915 inch
- Height from the surface: 18.25 mm / 0.719 inch
- Depth: 11.6 mm / 0.457 inch
- Solder pin length: 5 mm
- Solder pin dimensions: 0.6 x 1 mm
- Drilled hole diameter (tolerance): (− … +0.1) 1.3 mm
- Contact type (pluggable connector): Female connector/socket
- Connector connection type: for PCBs
- Mismating protection: No
- Mating direction to the PCB: 90 °
- PCB contact: THT
- Solder pin arrangement: over the entire female connector, in line
- Number of solder pins per potential: 1
- Color: gray
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.083 MJ
- Weight: 4.7 g
- Limit temperature range: -60 … +85 °C
- Product Group: 3 (Multi Conn. System)
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918578325
- Customs Tariff No.: 85366990990
