WAGO 26161354 PCB Terminal Block
This is a 4-pole PCB terminal block with lever-actuated Push-in CAGE CLAMP® connections, designed for solid and ferruled conductors. Its intuitive, tool-free design allows multiple clamping units to be opened simultaneously, simplifying multi-core cable termination. Testing is versatile, enabling measurement both parallel and perpendicular to conductor entry. Made from grey polyamide (PA66) with a UL94 V0 flammability class, it features high ratings: 800V, 76A, and complies with standards including IEC, UL, and CSA. Its compact dimensions (width 56.5mm, height 37.2mm) ensure reliability and ease of installation in electrical assemblies.
WAGO 26161354 PCB Terminal Block Specifications:
- Pole count: 4
- Pin spacing: 15 mm
- Width: 56.5 mm
- Height: 37.2 mm
- Depth: 32 mm
- Solder pin length: 4 mm
- Solder pin dimensions: 1.2 x 1.2 mm
- Conductor cross-section (solid): 0.75 ... 16 mm² / 18 ... 4 AWG
- Conductor cross-section (ferruled): 0.75 ... 25 mm² / 18 ... 4 AWG
- Rated voltage: 800 V
- Rated surge voltage: 8 kV
- Rated current: 76 A
- Material: Polyamide 66, gray, UL94 V0
- Contact material: Electrolytic copper, tin-plated
- Clamping spring: Chrome nickel spring steel
- Connection technology: Push-in CAGE CLAMP
- Actuation: Lever
- Environmental temperature: -60°C to +105°C
- Approvals: UL, CSA, KEMA
Buy the WAGO Series 2616 PCB Terminal Block: 4-Pole Lever Actuated Push-in CAGE CLAMP
Purchase the WAGO Series 2616 four-pole PCB terminal block online today and benefit from quick, tool-free wiring with Push-in CAGE CLAMP® technology. Its compact size, high current capacity of 76A, and broad voltage ratings up to 800V make it ideal for reliable electrical connections in both industrial and control applications. Made from UL94 V0-rated polyamide, it ensures safety and durability. This high-quality terminal block simplifies installation, offers versatile testing options, and is compliant with international safety standards, making it a top choice for electrical engineers and technicians.
Order your WAGO Series 2616 4-Pole PCB Terminal Block today and ensure reliable, tool-free wiring for your electrical projects.
