WAGO 721206026000 6-pole female connector
The WAGO 721-206/026-000 is a 6-pole female connector within the MCS – MULTI CONNECTION SYSTEM. It is designed for universal conductor types and offers 100% protection against mismating, ensuring reliable connections in industrial environments. The connector utilizes the innovative CAGE CLAMP® connection technology, simplifying cable pre-assembly and on-unit wiring. Integrated test ports provide convenient testing capabilities. It is suitable for applications requiring robust and secure connections, and is often paired with compatible male headers for complete connection solutions. Always observe the further product documentation for proper usage and safety guidelines.
WAGO 721206026000 6-pole female connector Specifications:
- Rated voltage (III/3): 500 V
- Rated surge voltage (III/3): 6 kV
- Rated voltage (III/2): 630 V
- Rated surge voltage (III/2): 6 kV
- Rated voltage (II/2): 1000 V
- Rated surge voltage (II/2): 6 kV
- Rated current: 16 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage UL (1977): 600 V
- Rated current UL (1977): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor; with insulated ferrule: 0.25 … 1.5 mm²
- Fine-stranded conductor; with uninsulated ferrule: 0.25 … 2.5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- Pole No.: 6
- Total number of connection points: 6
- Total number of potentials: 6
- Number of connection types: 1
- Pin spacing: 7.5 mm / 0.295 inch
- Width: 44 mm / 1.732 inch
- Height: 14.3 mm / 0.563 inch
- Depth: 26.45 mm / 1.041 inch
- Contact type (pluggable connector): Female connector/socket
- Mismating protection: Yes
- Color: light gray
- Insulation material: Polyamide (PA66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.207 MJ
- Weight: 12.7 g
- Limit temperature range: -60 … +85 °C
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918357210
- Customs tariff number: 85366990990
