WAGO 721606019000 6 Pole Connector Block
The WAGO 721-606/019-000 is a robust 6-pole connector block engineered for reliable power and signal transmission in industrial applications. Featuring a fixing flange, it provides secure mounting options for parallel or perpendicular installations. The 5mm pin spacing ensures compatibility with a wide range of wiring configurations. Its design incorporates 100% protection against mismating, enhancing safety and simplifying installation. Utilizing WAGO's innovative CAGE CLAMP® connection technology, this connector block guarantees a secure and vibration-resistant connection for solid conductors ranging from 0.08 to 2.5 mm².
WAGO 721606019000 6 Pole Connector Block Specifications:
- product_description: MALE CONNECTOR WITH FIXING FLANGE 6 POLE PIN SPACING 5 MM / 0.197 IN 100% PROTECTED AGAINST MISMATING WITHOUT PRECEDING GROUND CONTACT FOR SCREW OR SIMILAR MOUNTING TYPES FOR PARALLEL OR PERPENDICULAR MOUNTING
- packing_unit: 50 pieces
- color: light gray
- no_of_connection_points: 6
- no_of_potentials: 6
- pole_count: 6
- height: 14.3 mm / 0.563 in
- width: 44.8 mm / 1.764 in
- depth: 27.5 mm / 1.083 in
- pin_spacing_from: 5 mm / 0.197 in
- pollution_degree: 2
- measured_voltage_en: 320 V / 630 V
- measured_shock_voltage: 4 kV
- current_intensity_en: 12 A
- cross_section_mm2: 0.08 - 2.5 mm² solid
- cross_section_mm2_2: 0.25 - 1.5 mm²
- cross_section_mm2_3: 0.25 - 2.5 mm²
- cross_section_awg: 28 - 12 AWG
- strip_length_from: 8 mm
- strip_length_to: 9 mm
- material_group: I Strain relief plate
- admission_office: ABS, BV, CCA, DNV, GL, KEMA, LR, RMR
- approval_no: 04-HG469925/1-PDA, 11915/A0, 5764, E-9218, 17296-00HH, 2083746.02, 96/20035, 11130002
- voltage_approval: 250 V
- current_approval: 12 A
