WAGO 745603006000 Terminal Strip with Jumper Slot
The WAGO 745-603/006-000 is a 3-pole terminal strip designed for printed circuit board applications. It incorporates a jumper slot for flexible circuit design and utilizes WAGO’s innovative CAGE CLAMP® connection technology, ensuring a secure and vibration-resistant connection for wires ranging from 0.2 to 16 mm². The strip’s compact dimensions and robust construction make it suitable for a variety of industrial automation, power distribution, and control panel applications. Its gray color and pollution degree 2 rating indicate suitability for general industrial environments. The product may differ from the image provided.
WAGO 745603006000 Terminal Strip with Jumper Slot Specifications:
- Product Description: Terminal strip with jumper slot
- Number of Poles: 3
- Pin Spacing: 15 mm / 0.591 in
- Height: 27 mm / 1.06 in
- Width: 41.7 mm / 1.642 in
- Depth: 33.4 mm / 1.315 in
- Connection Method: CAGE CLAMP® CONNECTION
- Wire Strip Length: 12 mm
- Wire Strip Length To: 13 mm
- Cross Section (mm²): 0.2 - 16 mm²
- Cross Section (AWG): 24 - 6 AWG
- Measured Voltage: 1000 V
- Measured Shock Voltage: 8 kV
- Current Intensity: 76 A
- Pollution Degree: 2
- Material Group: blue light gray green-yellow light green light gray / RAL 7035
- Fixing Flange: with fixing flange
Buy the 745-603/006-000 WAGO Terminal Strip with Jumper Slot | myMectronic
Purchase the WAGO 745-603/006-000 terminal strip securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 745603006000?
You can click on the BUY or RFQ button to purchase 745603006000 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 745603006000?
You can download the 745603006000 datasheet or visit the WAGO website for support.
Who is the manufacturer of 745603006000?
WAGO
