WAGO 26243106 6-pole PCB Terminal Block
The WAGO 2624-3106 is a robust 6-pole PCB terminal block designed for reliable connections in a variety of industrial applications. Utilizing the innovative Push-in CAGE CLAMP technology, this terminal block ensures secure termination of both solid and ferruled conductors. Its compact design and 90° conductor entry angle make it ideal for panel feedthrough applications. The block is rated for a nominal voltage of 320V and a rated current of 41A, making it suitable for demanding electrical environments. It is also compliant with various international standards and approvals, ensuring safety and performance.
WAGO 26243106 6-pole PCB Terminal Block Specifications:
- Rated Voltage (III/3): 320 V
- Rated Surge Voltage (III/3): 4 kV
- Rated Voltage (III/2): 400 V
- Rated Surge Voltage (III/2): 4 kV
- Rated Voltage (II/2): 630 V
- Rated Surge Voltage (II/2): 4 kV
- Rated Current: 41 A
- Rated Voltage UL (Use Group B): 300 V
- Rated Current UL (Use Group B): 26 A
- Rated Voltage UL (Use Group D): 300 V
- Rated Current UL (Use Group D): 10 A
- Rated Voltage CSA (Use Group B): 300 V
- Rated Current CSA (Use Group B): 26 A
- Rated Voltage CSA (Use Group D): 300 V
- Rated Current CSA (Use Group D): 5 A
- Connection Technology: Push-in CAGE CLAMP®
- Solid Conductor Size: 0.2 … 6 mm² / 24 … 10 AWG
- Fine-Stranded Conductor Size: 0.2 … 6 mm² / 24 … 10 AWG
- Fine-Stranded Conductor with Ferrule Size: 0.25 … 2.5 mm²
- Fine-Stranded Conductor with Uninsulated Ferrule Size: 0.25 … 2.5 mm²
- Fine-Stranded Conductor with Twin Ferrule Size: 0.25 … 1.5 mm²
- Strip Length: 10 … 12 mm / 0.39 … 0.47 inch
- Conductor Connection Direction: 90 °
- Pole Number: 6
- Total Connection Points: 6
- Total Potentials: 6
- Pin Spacing: 5 mm / 0.197 inch
- Width: 31.5 mm / 1.24 inch
- Height: 20.3 mm / 0.799 inch
- Height from Surface: 16.3 mm / 0.642 inch
- Depth: 15.4 mm / 0.606 inch
- Solder Pin Length: 4 mm
- Solder Pin Dimensions: 0.8 x 1 mm
- Drilled Hole Diameter: 1.3 (+0.1) mm
- Material Group: I
- Insulation Material: Polyamide (PA66)
- Flammability Class: V0
- Clamping Spring Material: Chrome nickel spring steel (CrNi)
- Contact Material: Electrolytic copper (E) Cu
- Contact Plating: tin-plated
- Weight: 9.7 g
- Limit Temperature Range: -60 … +105 °C
