WEIDMULLER 1330510000 LMF LMFS PCB Terminal Block
The Weidmuller LMF LMFS 5.00/08/180 3.5SN OR BX PCB terminal block is designed to meet current market requirements for PCB terminals. It utilizes a PUSH IN connection system, accommodating wire cross-sections up to 2.5 mm². The integrated test point simplifies testing and troubleshooting, while the 180° wire outlet direction provides flexibility in routing. This terminal block is suitable for a variety of industrial applications requiring reliable and efficient PCB connections.
WEIDMULLER 1330510000 LMF LMFS PCB Terminal Block Specifications:
- Base Material: CuSn
- Coating: 4-6μm SN
- Insulating Material: Wemid (PA)
- Color: Orange
- Net Weight: 11.13 g
- Pitch: 5 mm
- Number of Poles: 8
- Solder Pin Length: 3.5 mm
- Clamping Range Min: 0.12 mm²
- Clamping Range Max: 2.5 mm²
- Wire Connection Cross Section AWG Min: AWG 24
- Wire Connection Cross Section AWG Max: AWG 12
- Rated Current Min: 24 A
- Rated Current Max: 24 A
- Rated Voltage: 400 V
- Impulse Voltage: 4 kV
- Flammability Rating: V-0
- Storage Temperature Max: 55 °C
- Operating Temperature Min: -50 °C
- Operating Temperature Max: 120 °C
- Stripping Length: 10 mm
- Screwdriver Blade: 0.6 x 3.5
