WEIDMULLER 2473050000 Power PCB Terminal
The OMNIMATE Power series LLFS 7.50/07/90V 5.0SN BK BX is a robust PCB terminal designed for high-current and voltage applications in power electronics. Suitable for solar inverters, frequency converters, and power supplies, it features a 7.50 mm pitch, 7 poles, and a solder pin length of 5 mm. Its push-in connection method ensures secure wiring without the need for a latch, supporting wire sizes from 0.25 mm² to 6 mm². Crafted from insulating Wemid (PA) with a black, V0-flammability rated surface, it offers a rated voltage of 1000 V and current of up to 41A, complying with IEC, UL, and CSA standards. Designed for reliable, finger-safe connections, it ensures long-term durability with a temperature range of -40°C to +120°C.
WEIDMULLER 2473050000 Power PCB Terminal Specifications:
- Width: 53.5 mm (2.106 inches)
- Height: 30.56 mm (1.203 inches)
- Depth: 20.05 mm (0.789 inches)
- Solder pin length: 5 mm
- Number of poles: 7
- Pitch: 7.5 mm (0.295 inches)
- Insulating material: Wemid (PA), black, UL 94V-0
- Contact material: Tinned copper (E-Cu)
- Rated voltage: 1000 V (IEC), 600 V (UL/CSA)
- Rated current: 41A (IEC), 37A (UL/CSA)
- Clamping range: 0.25 mm² to 6 mm² for wire cross-section
- Operating temperature: -40°C to +120°C
- Storage temperature: -40°C to +70°C
- Flammability: V0
- Protection class: IP20
- Connection method: Push-in without actuator, THT soldering
- Certification: IEC, UL, CSA
Buy the Weidmueller Series LL Power PCB Terminal: 2473050000
Enhance your power electronics projects with the Weidmueller Series LL Power PCB Terminal, offering secure push-in connection, high current capacity, and IP20 protection. With a 7-pole configuration and a 7.5 mm pitch, this terminal ensures reliable wiring for solar inverters, frequency converters, and power supplies. Crafted for durability under extreme temperatures, it supports wire sizes from 0.25 mm² to 6 mm² and complies with IEC, UL, and CSA standards. Easy to install and long-lasting, it’s the perfect choice for demanding electrical applications.
Buy Weidmueller Series LL Power PCB Terminal 2473050000 now and experience unmatched reliability and performance in high-current power electronics applications.
Frequently Asked Questions
Where can I buy WEIDMULLER 2473050000?
You can click on the BUY or RFQ button to purchase 2473050000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 2473050000?
You can download the 2473050000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 2473050000?
WEIDMULLER
