WEIDMULLER SL351290G Pin Header
This high-quality pin header offers a robust THT solder connection with a 3.50 mm pitch, 12 poles, and a 90° plugging direction for reliable PCB connectivity. Encased in an orange PBT housing with screw flange, it supports up to 300V/10A ratings per IEC, UL, and CSA standards. Designed for wave soldering, the pin length is 3.2 mm, with a contact surface of tin-plated CuSn contact material. It features a compact, lightweight design weighing 3.66 g, suitable for automation and electronic applications requiring precise, durable connections.
WEIDMULLER SL351290G Pin Header Specifications:
- Pitch: 3.50 mm (0.138 inch)
- Number of poles: 12
- Solder pin length: 3.2 mm (+0.1/-0.3 mm)
- Pin dimension: d=1.2 mm, octagonal
- Solder eyelet diameter: 1.4 mm
- Housing material: PBT, orange
- Rated voltage: 300V
- Rated current: 10A
- Tinned CuSn contact surfaces
- Insulation resistance: 210 MΩ at 500 V
- Operating temperature: -60°C to 100°C
- Max storage humidity: 80%
- Packaging: box of 50 pieces
- Dimensions: length 38.5 mm (1.516 inch), width varies
- Touch-safe protection: Yes, per DIN VDE
- Plugging cycles: 25
- Withdrawal force: 8N per pole
- Push-in force: 10N per pole
- UL/CSA approval: 300V/10A
- RoHS compliant
- Flammability rating: UL 94V-0
Buy the Buy Weidmuller Pin Header Part Number SL351290G Online
Purchase the Weidmuller pin header SL351290G online today for unmatched reliability in PCB assembly. Featuring a 3.50mm pitch, 12 poles, THT solder connection, and rated 300V/10A, this connector ensures durable electrical contacts suitable for automation, electronics, and industrial applications. Its orange PBT housing provides excellent insulation and resistance to high temperatures, making it ideal for wave soldering processes. With TOUCH-SAFE protection, a compact design, and UL/CSA approval, buy online now to guarantee top-quality connectivity in your projects.
Buy Weidmuller SL351290G now and experience reliable PCB connections with robust wave soldering compatibility and durable orange housing.
Frequently Asked Questions
Where can I buy WEIDMULLER SL351290G?
You can click on the BUY or RFQ button to purchase SL351290G from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part SL351290G?
You can download the SL351290G datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of SL351290G?
WEIDMULLER
