XP POWER AH01P12 High Voltage Converter
The AH Series ultra-miniature high-voltage DC converters offer a compact design occupying less than 0.1 cubic inches with a profile of just 0.250 inches. They deliver adjustable output voltages from 100V to 6000V, proportional to the input voltage, with a linear response. Features include a 0.7VDC turn-on voltage, input-output isolation, short circuit protection, and external control pin for precise regulation. Suitable for high-voltage power supplies, electrophoresis, photo multiplier tubes, and sensing applications in confined spaces demanding reliable, high-voltage output and minimal footprint.
XP POWER AH01P12 High Voltage Converter Specifications:
- Output Voltage: 100V to 6000V
- Output Current: Up to 15mA depending on model
- Input Voltage: 7V, 12V, 24V DC
- Input to Output Isolation: 500V
- Turn-on Voltage: 0.7VDC
- Ripple and Noise: Up to 5%
- Operating Temperature: -25°C to +85°C
- Storage Temperature: -55°C to +105°C
- Construction: Solid vacuum encapsulation, UL 94V-0 rated
- Cooling: Natural convection
- Switching Frequency: 50-350 kHz
- Dimensions: Height x Width 0.25 x 0.45 inches (6.35 x 11.43mm), Length varies by model from 0.92 to 1.33 inches
- Weight: Under 0.3 ounces
- Safety Approvals: UL, IEC/UL/CSA EN 62368, RoHS compliant
- Leakage Current: 100mA
- Isolation: Input to Output 500V
- Short Circuit Protection: Yes, for at least 1 minute
Buy the Buy XP Power High Voltage Converter Part Number AH01P12 Online
Purchase the XP Power AH Series high voltage converters online today to benefit from their compact size, adjustable high voltage output from 100V to 6000V, and robust protection features. Ideal for electrophoresis, photo multiplier tubes, and low-profile power applications, these converters deliver reliable, linear input-output response with a 0.7VDC turn-on voltage. With no minimum load requirements, input-to-output isolation, and UL safety approval, they provide a dependable high-voltage power supply solution suitable for demanding scientific and industrial projects. Shop now for fast delivery and quality assurance.
Order your XP Power SeriesAH01P12 high voltage converter today and ensure reliable, compact power solutions for electrophoresis, sensors, and research projects.
Frequently Asked Questions
Where can I buy XP POWER AH01P12?
You can click on the BUY or RFQ button to purchase AH01P12 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part AH01P12?
You can download the AH01P12 datasheet or visit the XP POWER website for support.
Who is the manufacturer of AH01P12?
XP POWER
