XP POWER VEP24US24 Power Supply
The VEP24US24 is a high-efficiency 36-watt power supply designed for reliable output with 15V at 2.4A, featuring UL 94V-0 class case, adjustable voltage, and universal input compatibility. It boasts a compact form factor, low ripple, and noise levels, making it suitable for various industrial and electronic applications. The device complies with multiple safety standards and offers options for different plug types, ensuring versatility and safety in diverse environments. Its excellent MTBF and wide operating temperature make it ideal for demanding use cases.
XP POWER VEP24US24 Power Supply Specifications:
- Output Power: 36W
- Output Voltage: 15.0V
- Output Current: 2.4A
- Ripple & Noise: 100 mV
- Efficiency: 86%
- Input Voltage: 80-264 VAC
- Input Frequency: 47-63 Hz
- Surge Capacity: 28.0V trip point
- Isolation: 3000 VAC Input to Output
- Switching Frequency: 65 kHz typical
- Operating Temperature: 0°C to +40°C
- Cooling: Natural convection
- MTBF: 200,000 hours
- Case Material: PC Class 94V-0
- Case Dimensions: 2.09 x 0.39 x 1.67 inches (53.1 x 10 x 42.4 mm)
- Weight: approximately 0.57 lbs (260 g)
- Certifications: EN60950-1, UL60950-1, IEC60950-1
- Output Plug: Inner Positive 0.5.5 x 0.2.5 x 11.0 mm
- Optional plug types: UK, EU, CN, US, AU
Buy the Power Supply Series 24V 36W: VEP24US24
Purchase the VEP24US24 power supply online today to enjoy efficient, safe, and reliable power with versatile plug options. Perfect for industrial, medical, and electronic applications, this unit ensures steady performance with a high MTBF and wide temperature range. Its compact design and low ripple noise make it ideal for sensitive equipment. Trust in its compliance with global safety standards and enjoy quick delivery, excellent customer support, and a seamless online shopping experience for all your power needs.
Buy VEP24US24 power supply now and experience unmatched reliability and versatile performance for your electronic projects.
Frequently Asked Questions
Where can I buy XP POWER VEP24US24?
You can click on the BUY or RFQ button to purchase VEP24US24 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part VEP24US24?
You can download the VEP24US24 datasheet or visit the XP POWER website for support.
Who is the manufacturer of VEP24US24?
XP POWER
