XP POWER IA0505S Dual Output DC-DC Converter
The IA Series offers compact, cost-effective dual output DC-DC converters in SIP and DIP packages, ideal for process control and instrumentation. Operating from 3.3V to 29V inputs, they deliver regulated outputs with efficiencies up to 80% and 1kV isolation. Designed for reliable performance in industrial environments, they feature high MTBF over 1.1 million hours, operating temperature up to +85°C, and meet safety standards UL and CSA. Suitable for various applications requiring reliable power conversion in space-constrained designs.
XP POWER IA0505S Dual Output DC-DC Converter Specifications:
- Input Voltage Range: 3.3V to 29V nominal
- Output Voltage Options: 3.3V, 5V, 12V, 15V, 24V, 29V
- Output Current: up to 100 mA to 242 mA depending on model
- Efficiency: Up to 80%
- Isolation Voltage: 1kV DC
- Isolation Resistance: 1 GΩ
- Isolation Capacitance: 60 pF
- Switching Frequency: 80 kHz (varies by model)
- Operating Temperature: -40°C to +85°C
- MTBF: Over 1.1 million hours
- Weight: SIP approximately 2.3 g, DIP approximately 2.6 g
- Case Material: Non-conductive UL94V-0 plastic
- Solder Material: Alloy 42, nickel-coated
- Environmental: Water-washable with de-ionized water, UL and CSA safety compliance
Buy the XP Power Series IA DC-DC Converter: IA0505S
Enhance your electronic projects with the XP Power Series IA0505S dual output DC-DC converter, offering reliable 1kV isolation, high efficiency, and compact SIP or DIP packages. Perfect for process control, instrumentation, and logic circuits, these converters are designed for durability with an operating temperature up to +85°C and a proven MTBF over 1.1 million hours. Secure your supply today by ordering online and enjoy the convenience of fast delivery and superior quality for demanding industrial applications.
Order your XP Power Series IA0505S compact dual output DC-DC converter today and ensure reliable power in your industrial control and instrumentation projects.
Frequently Asked Questions
Where can I buy XP POWER IA0505S?
You can click on the BUY or RFQ button to purchase IA0505S from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part IA0505S?
You can download the IA0505S datasheet or visit the XP POWER website for support.
Who is the manufacturer of IA0505S?
XP POWER
