XP POWER ICZ0948S24 DC-DC Converter
The ICZ Series DC-DC Converter by XP Power delivers 9 watts of reliable power with a compact SIP8 package, ideal for space-constrained applications. It features a 2:1 input range, operating temperature from -40°C to +85°C, and 1.6kVDC input-to-output isolation. Fully regulated output ensures stable voltage, with no minimum load required. Its small footprint and remote on/off capability make it perfect for industrial, automation, and control systems where dependable power conversion and compact size are essential for efficient operation and space saving.
XP POWER ICZ0948S24 DC-DC Converter Specifications:
- Input Voltage Range: 18V to 36V (24V nominal), 36V to 75V (BV), 70V to 150V, 240V
- Output Power: 9 Watts
- Output Voltage: 3.3V, 5V, 12V, 15V, 24V options
- Efficiency: Up to 87%
- Operating Temperature: -40°C to +85°C (derating above 50°C), 100% load at -40°C, no load at +85°C
- Isolation Voltage: 1.6kVDC input to output, 7000V input to case
- Remote On/Off feature: Input voltage 0-5V, with 4mA max current
- Dimensions: 0.86 x 0.38 x 0.44 inches (21.8 x 9.6 x 11.2 mm)
- Weight: Approximately 0.016 lbs (73 g)
- Input Surge Voltage: Up to 700V for 100 ms
- Protection: Continuous short circuit and overload protection, auto recovery
- Safety & Compliance: UL/cUL listed, reinforced insulation, EMI filter, line and load regulation
- Switching Frequency: 200/500 kHz
- Input reflected ripple: 30 mA pk-pk
- Leakage current: 15 mA
- Case Material: Copper with epoxy potting
- Certifications: UL, CSA compliant
Buy the XP Power Series ICZ DC-DC Converter: ICZ0948S24
Looking for a reliable and compact power solution? The XP Power ICZ series 9-watt DC-DC converter combines a small SIP8 form factor with advanced features like full regulation, remote on/off, and high efficiency. Perfect for industrial control, automation, and space-constrained applications, this converter offers excellent isolation, a broad input voltage range, and robust overload and short circuit protection. Buy online now to streamline your projects with a trusted power conversion component that delivers performance and durability.
Order your XP Power Series ICZ0948S24 compact DC-DC converter today and ensure your industrial projects benefit from dependable, high-performance power conversion.
Frequently Asked Questions
Where can I buy XP POWER ICZ0948S24?
You can click on the BUY or RFQ button to purchase ICZ0948S24 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ICZ0948S24?
You can download the ICZ0948S24 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ICZ0948S24?
XP POWER
