XP POWER ITB1205S DC-DC Converter
The ITB Series DC-DC Converter delivers 1 watt of reliable power with single outputs, enhanced isolation of 1500 VDC, and operation across -40 °C to +105 °C. Its SIP package makes it suitable for compact applications, offering full load capacity at high temperatures and class B emissions for compliant performance. Its robust construction ensures MTBF over 3.5 million hours with a 3-year warranty, making it ideal for industrial and automation projects demanding dependable energy conversion.
XP POWER ITB1205S DC-DC Converter Specifications:
- Power Rating: 1 Watt
- Input Voltage Range: 5V, 12V, 15V, 24V options
- Output Voltage Range: 5V, 12V, 15V
- Output Current: 200 mA (max)
- Isolation Voltage: 1500 VDC
- Operating Temperature: -40°C to +105°C
- Full Load at 95°C Ambient
- Efficiency: 80-81%
- MTBF: >3.5 million hours
- Dimensions: 0.76 x 0.24 x 0.39 inches (19.5 x 6.0 x 10.0 mm)
- Weight: Approx. 0.0083 lbs (4 g)
- Certifications: Class B Conducted & Radiated Emissions
- Surge Voltage: 8 VDC (1000 ms), 30 VDC (1000 ms, 24V models)
- Ripple & Noise: 60 mV pk-pk
- Isolation Resistance: 10^2 ohms
- Switching Frequency: 40/50 kHz
- Case Material: SIP Package, natural convection cooling
- Mechanical Tolerances: Pin diameter 0.02+0.002 inches, pitch +0.014 inches
- Environmental Compliance: EN61000-4-2, EN61000-4-4, EN61000-4-5 for immunity
- Temperature Coefficient: 0.02 %/°C
Buy the XP Power Series ITB1205S DC-DC Converter: 1W, 1500 VDC Isolation, -40°C to +105°C Operation
Experience reliable power conversion with the XP Power Series ITB1205S DC-DC Converter, offering 1 watt output, 1500 VDC isolation, and a wide temperature range from -40°C to +105°C. Its SIP package ensures compactness and ease of installation in confined spaces. Designed for industrial environments, it maintains full load capacity at high temperatures, features Class B emissions to meet regulatory standards, and boasts a MTBF exceeding 3.5 million hours for long-term dependability. Secure your supply by purchasing online today for optimal project performance.
Order your XP Power Series ITB1205S DC-DC Converter today and give your industrial projects the dependable, high-quality power they deserve.
Frequently Asked Questions
Where can I buy XP POWER ITB1205S?
You can click on the BUY or RFQ button to purchase ITB1205S from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITB1205S?
You can download the ITB1205S datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITB1205S?
XP POWER
