XP POWER ITP0312S3V3 DC-DC Converter Module
The ITP series is a compact and cost-effective 3W DC-DC converter module designed with robust encapsulation and a wide input voltage range. It provides regulated single or dual outputs from 3.3V to 15V DC, with high efficiency and 1% output regulation. Suitable for industrial applications, it features a 4:1 input range (4.5–18V, 9–36V, or 18–75V DC), 1.6kV DC input/output isolation, and operates from -40°C to +75°C, delivering full power up to 70°C. Additional features include short-circuit protection and remote On/Off control (for single output models). It also complies with EN55032 standards.
XP POWER ITP0312S3V3 DC-DC Converter Module Specifications:
- Power: 3 Watts
- Input Voltage Range: 4.5-18V, 9-36V, 18-75V DC
- Output Voltage: 3.3V, 5V, 12V, 15V
- Output Current: 200-700 mA depending on model
- Isolation: 1.6kV DC input/output
- Operating Temperature: -40°C to +75°C
- Full Power Operating Temp: up to +70°C
- Efficiency: up to 84%
- Package: SIP6 encapsulated
- Short-circuit Protection: Yes
- Remote On/Off: Yes (single output models)
- MTBF: >0.95 million hours
- Standards: EN55032, UL 62368-1, CE LVD
Buy the XP Power ITP Series – Reliable 3W DC-DC Converter for Industrial Applications
Purchase the XP Power ITP Series 3W DC-DC converter module online today for a reliable and efficient power source. Its robust encapsulation and wide input voltage range make it suitable for industrial environments. With high efficiency, low ripple, and short-circuit protection, it ensures your equipment operates safely and reliably. Ideal for industrial automation, instrumentation, and control systems, this compact module operates from -40°C to +75°C, providing regulated outputs up to 15V. Secure your power requirements now with fast online ordering.
Order your XP Power ITP Series 3W DC-DC Converter today and enhance your industrial projects with dependable, compact power solutions.
Frequently Asked Questions
Where can I buy XP POWER ITP0312S3V3?
You can click on the BUY or RFQ button to purchase ITP0312S3V3 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITP0312S3V3?
You can download the ITP0312S3V3 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITP0312S3V3?
XP POWER
