XP POWER ITB1212S DC-DC Converter
The ITB1212S is a compact, high-efficiency DC-DC converter designed for industrial applications requiring 12V output at 80% efficiency, with excellent isolation and wide temperature range. It features a SIP package, measuring 0.76 x 0.24 x 0.39 inches (19.5 x 6.0 x 10.0 mm), and can operate from -40°C to +105°C. With a maximum load capacity of 106 mA, it provides 1500 VDC isolation, low ripple, and noise, making it ideal for embedded systems, automation, and control systems with stringent performance standards.
XP POWER ITB1212S DC-DC Converter Specifications:
- Input Voltage Range: 8V to 36V DC
- Output Voltage: 12V ±5%
- Output Current: 106mA (full load)
- Efficiency: 80%
- Isolation Voltage: 1500 VDC
- Operating Temperature: -40°C to +105°C
- Dimensions: 0.76 x 0.24 x 0.39 inches (19.5 x 6.0 x 10.0 mm)
- Package: SIP
- Ripple & Noise: 100 mV pk-pk
- Isolation Resistance: 10^2 MΩ
- Switching Frequency: 40/50 kHz
- MTBF: >3.5 million hours
- Certifications: UL, CE
- Weight: 0.0083 lbs (3.8 g)
Buy the Buy XP Power ITB1212S Part Number ITB1212S Online
Purchase the high-quality XP Power DC-DC converter, model ITB1212S, online today. This compact, SIP-package power supply offers 12V output, 1500V isolation, and operates from -40°C to +105°C, ensuring reliable performance in demanding industrial environments. With efficiency reaching 80%, low ripple, and noise, it is ideal for automation, embedded systems, and control applications. Our online store provides fast delivery, secure checkout, and expert support to meet your power conversion needs efficiently.
Buy XP Power ITB1212S now and experience unmatched reliability and high performance in your industrial power conversion needs.
Frequently Asked Questions
Where can I buy XP POWER ITB1212S?
You can click on the BUY or RFQ button to purchase ITB1212S from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITB1212S?
You can download the ITB1212S datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITB1212S?
XP POWER
