XP POWER JTR1024S24 DC-DC Converter
The JTR10 Series is a compact, regulated DC-DC converter offering 10 Watts of power with wide input voltage ranges of 9–36V or 18–75VDC. Featuring high efficiency up to 87% and full power operation from -40°C to +85°C, it includes dual outputs such as +12V and +15V. It is housed in a DIP16 metal case with optional output voltage trimming of +10%. Designed for industrial applications, it complies with safety standards like UL, IEC, and cUL (pending) and has a MTBF exceeding 500,000 hours. Its reliable power solutions are ideal for automation and control systems.
XP POWER JTR1024S24 DC-DC Converter Specifications:
- Input Voltage Range: 9–36V or 18–75VDC
- Output Power: 10 Watts
- Output Voltage: 3.3V to 30VDC, dual outputs +12V and +15V
- Efficiency: Up to 87%
- Operating Temperature: -40°C to +85°C
- Full Power at 470°C ambient
- MTBF: >500,000 hours
- Case Material: Black coated copper with non-conductive plastic base (UL94V-0)
- Dimensions: 0.94 x 0.54 x 0.41 inches (23.8 x 13.7 x 10.3 mm)
- Switching Frequency: 370 kHz
- Isolation: Input to output 1500 VAC for 60 seconds
- Safety Approvals: Pending IEC/UL/cUL 62368-1
Buy the XP Power JTR10 Series – Reliable DC-DC Converter for Industrial Applications
Purchase the XP Power JTR10 Series DC-DC converter online today and enjoy reliable, efficient power solutions designed for industrial automation, control systems, and harsh environments. Its wide input voltage range and high efficiency make it ideal for demanding applications requiring consistent performance. With a compact DIP16 metal case, full power operation at high temperatures, and compliance with safety standards, this converter guarantees durability and safety. Get your order now to enhance your project’s power management with a trusted, industrial-grade component.
Order your XP Power JTR10 Series 10 Watts DC-DC converter today and ensure dependable power delivery for your industrial and automation projects.
Frequently Asked Questions
Where can I buy XP POWER JTR1024S24?
You can click on the BUY or RFQ button to purchase JTR1024S24 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part JTR1024S24?
You can download the JTR1024S24 datasheet or visit the XP POWER website for support.
Who is the manufacturer of JTR1024S24?
XP POWER
