XP POWER ITP0312D05 DC-DC Converter Module
The ITP series offers a compact 3W DC-DC converter module with a wide input voltage range and precise 1% regulation. It features regulated single and dual outputs from 3.3V to 15V DC, an ultra-compact SIP6 package, and 1.6kV DC input/output isolation. The module is designed for industrial applications, providing high efficiency, short-circuit protection, remote On/Off (for single-output models), and an operating temperature range from -40°C to +75°C. Full power operation is supported up to +70°C, ensuring reliable performance in various settings.
XP POWER ITP0312D05 DC-DC Converter Module Specifications:
- Power: 3 Watts
- Input Voltage Range: 4.5-18V, 9-36V, 18-75VDC
- Output Voltage: 3.3V, 5V, 12V, 15V (regulated, -40°C to +75°C)
- Input/Output Isolation: 1.6kVDC
- Efficiency: Up to 83%
- Operating Temperature: -40°C to +75°C (full power to +70°C)
- Physical Size: 0.67 x 0.46 x 0.46 inches (17.0 x 11.7 x 11.7 mm)
- Packaging: SIP6 encapsulated module
- Short-Circuit Protection: Yes
- Remote On/Off Control: Yes (single output models only)
- Certification: EN55032
- MTBF: >0.95 million hours
Buy the Buy XP Power DC-DC Converter Part Number ITP0312D05 Online
Purchase the XP Power DC-DC Converter Module online today for dependable 3W power with wide input voltage ranges, regulated outputs from 3.3V to 15V, and high efficiency up to 83%. This compact, industrial-grade module features 1.6kVDC isolation, short-circuit protection, and remote On/Off control, ensuring robust performance across -40°C to +75°C operating temperatures. Perfect for demanding applications requiring reliable, efficient power conversion in a small form factor, with a 3-year warranty for peace of mind.
Get XP Power ITP0312D05 today—built for precision, high efficiency, and reliable industrial power in compact size.
