XP POWER ITP0312D12 Industrial DC-DC Converter
The ITP series is a compact, cost-effective 3W DC-DC converter module designed for industrial applications. It features a wide input voltage range with regulation accuracy of 1%, and offers both single and dual output voltages from 3.3V to 15V. The device is housed in a robust SIP6 package, providing 1.6kVDC input/output isolation, high efficiency, and compliance with EN55032 standards. It includes short-circuit protection, remote On/Off (for single output versions), and operates reliably across a temperature range of -40°C to +75°C, delivering full power up to +70°C.
XP POWER ITP0312D12 Industrial DC-DC Converter Specifications:
- Power: 3 Watts
- Input Voltage Range: 4.5-18V, 9-36V, 18-75VDC
- Output Voltages: 3.3V, 5V, 12V, 15V, +5V, +12V, +15V
- Output Current: Up to 700 mA
- Isolation Voltage: 1.6kVDC
- Efficiency: Up to 84%
- Operating Temperature Range: -40°C to +75°C
- Full Power Operating Temp: up to +70°C
- Package: SIP6
- MTBF: >0.95 Million hours
- Dimensions: 17.0 x 10.1 x 11.7 mm
- Compliance: EN55032, UL62368-1, CE
Buy the XP Power ITP0312D12 – Reliable DC-DC Converter for Industrial Applications
Purchase the XP Power ITP0312D12 online today and benefit from a 3W industrial-grade DC-DC converter that offers wide input voltage range, high efficiency, and robust isolation. Designed for industrial applications, it features a SIP6 package for compactness, remote On/Off control, and operates reliably across -40°C to +75°C. With a regulation accuracy of 1%, it ensures stable voltage outputs—critical for your sensitive electronics—plus short-circuit protection and compliance with EN55032 standards for EMI noise reduction. Get yours now for seamless integration into your power systems.
Buy XP Power ITP0312D12 now and experience unmatched reliability and high efficiency in industrial environments.
Frequently Asked Questions
Where can I buy XP POWER ITP0312D12?
You can click on the BUY or RFQ button to purchase ITP0312D12 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITP0312D12?
You can download the ITP0312D12 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITP0312D12?
XP POWER
