XP POWER ITP0324S05 DC-DC Converter
The ITP series is a compact, cost-effective 3W DC-DC converter module designed for industrial use. It offers regulated single and dual outputs ranging from 3.3V to 15V with a typical regulation accuracy of 1%. The module features a wide 4:1 input voltage range (e.g., 4.5 to 18V, 9 to 36V, or 18 to 75V DC), and is housed in an ultra-compact SIP6 package. It provides 1.6kVDC input/output isolation, high efficiency, and complies with EN55032 standards. The converter includes short-circuit protection, remote On/Off (available on single-output models), and operates over an extended temperature range from -40°C to +75°C, delivering full power up to +70°C.
XP POWER ITP0324S05 DC-DC Converter Specifications:
- Power: 3 Watts
- Input Voltage Range: 4.5-18V, 9-36V, 18-75V DC
- Output Voltage: 3.3V, 5V, 12V, 15V (single & dual outputs)
- Output Current: up to 700 mA (varies by model)
- Regulation Accuracy: ±1%
- Isolation: 1.6kVDC input/output
- Efficiency: up to 84-83%
- Operating Temperature: -40°C to +75°C
- Full Power Operation: up to +70°C
- Package: SIP6 ultra-compact
- Short-circuit Protection: Yes
- Remote On/Off: Yes (single output models)
- Standards: EN55032 compliant
- MTBF: >0.95 million hours
- Warranty: 3 years
Buy the XP Power ITP0324S05 – Reliable DC-DC Converter for Industrial Applications
Secure the XP Power ITP0324S05 DC-DC converter online today and benefit from a cost-effective, high-efficiency power conversion solution for demanding industrial applications. This compact module delivers regulated outputs up to 15V DC, supports wide input voltage ranges, and features 1.6kVDC isolation. Its robust design ensures reliable operation from -40°C to +75°C, with full power output up to +70°C. Equipped with short-circuit protection and remote On/Off, it is ideal for industrial automation, instrumentation, and power management needs. Purchase now for dependable performance.
Buy XP Power ITP0324S05 now and experience unmatched reliability and performance with high efficiency and compact design suitable for industrial environments.
