XP POWER ITP0348D05 DC-DC Converter
The ITP series offers a compact 3W DC-DC power module that provides regulated single and dual outputs ranging from 3.3V to 15V. It features a wide input voltage range with options from 4.5V to 18V, 9V to 36V, and 18V to 75V, ensuring versatility for various applications. The module is housed in an ultra-compact SIP6 package, providing 1.6kVDC input/output isolation and high efficiency. It is designed for industrial temperature ranges, operating from -40°C to +75°C, with full power capability up to +70°C. Additional features include short-circuit protection and remote on/off control (for single-output versions). It complies with EN55032 standards and is suitable for demanding industrial environments.
XP POWER ITP0348D05 DC-DC Converter Specifications:
- Power: 3 Watts
- Input Voltage Ranges: 4.5 to 18V, 9 to 36V, 18 to 75V
- Output Voltage Options: 3.3V, 5.0V, 12.0V, 15.0V
- Output Current (Varies by model): 200 mA to 700 mA
- Efficiency: Up to 84%
- Input/Output Isolation: 1.6 kVDC
- Operating Temperature Range: -40°C to +75°C
- Full Power Operating Temp: Up to +70°C
- Package: SIP6 ultra-compact
- Protection: Short-circuit, overload
- Remote On/Off: Available on single output models
- Certification: EN55032 compliant
Buy the Buy XP Power DC-DC Converter Part Number ITP0348D05 Online
Order the XP Power ITP0348D05 DC-DC converter online today and benefit from a highly efficient, compact power module designed for demanding industrial environments. With wide input voltage ranges from 18V to 75V and multiple output options, this reliable device provides protected, regulated power with full isolation, short-circuit protection, and a rugged SIP6 package. Ideal for industrial automation, control systems, and embedded solutions, it ensures optimal performance across extended temperature ranges from -40°C to +75°C. Secure your power needs online today!
Buy XP Power ITP0348D05 now and experience unmatched reliability and performance in industrial power applications.
Frequently Asked Questions
Where can I buy XP POWER ITP0348D05?
You can click on the BUY or RFQ button to purchase ITP0348D05 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITP0348D05?
You can download the ITP0348D05 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITP0348D05?
XP POWER
