XP POWER ITQ2409SA Industrial DC-DC Converter
The ITQ series isolated 6W DC-DC converter offers fully regulated single and dual outputs within a broad 4:1 input voltage range. It provides 1500VDC isolation, supports remote On/Off control, and operates reliably between -40°C and 100°C. Its compact SIP 8 package makes it suitable for industrial sensing, instrumentation, automation, and process control. Features include no minimum load, high efficiency up to 87%, short circuit protection, and optional 3000VDC isolation, ensuring safety and performance in demanding environments.
XP POWER ITQ2409SA Industrial DC-DC Converter Specifications:
- Input Voltage Range: 18-75 VDC, nominal 24V
- Output Voltage: 3.3V to 24V options
- Output Power: 6W
- Isolation: 1500VDC (optional 3000VDC with suffix '-H')
- Efficiency: up to 87%
- Operating Temperature: -40°C to +100°C
- Case Size: SIP 8 package measuring approximately 0.86 x 0.36 x 0.44 inches
- Remote On/Off Control: yes, turns off when 2-4 mA applied
- Surge Voltage Tolerance: 50V for 100ms (24V models), 100V for 100ms (48V models)
- Ripple & Noise: 5 mV pk-pk (20 MHz bandwidth)
- Safety Compliance: UL62368-1, UL60950-1, CSA GSA
- Switching Frequency: 580 kHz
- Temperature Coefficient: 0.02 %
- Humidity: 5% RH non-condensing
- Cooling: Natural convection
- Weight: 4.8 g
Buy the XP Power ITQ2409SA – Reliable Industrial DC-DC Converter for Sensing and Automation
Secure your industrial projects today by purchasing the XP Power ITQ2409SA online. This 6W isolated DC-DC converter features regulated single and dual outputs, 1500VDC isolation, and a wide input range, ensuring reliable performance in sensing, instrumentation, automation, and process control systems. Its compact SIP 8 design, high efficiency up to 87%, and no minimum load requirement make it ideal for demanding environments. With remote On/Off, surge tolerance, and safety standards compliance, order now for dependable power solutions.
Buy XP Power ITQ2409SA now and experience unmatched reliability and high efficiency in industrial sensing and automation applications.
Frequently Asked Questions
Where can I buy XP POWER ITQ2409SA?
You can click on the BUY or RFQ button to purchase ITQ2409SA from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITQ2409SA?
You can download the ITQ2409SA datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITQ2409SA?
XP POWER
