XP POWER JTK2024S05 High-Performance Power Module
This high-performance power module features a wide 4:1 input voltage range, a compact 1x1 inch package, and operates efficiently from -40°C to +100°C. It offers 1600 VDC isolation and achieves up to 89% efficiency, making it ideal for power management and DC/DC conversion applications. It supports single and dual output configurations, includes overload and overvoltage protections, and adheres to safety standards. Its robust design ensures reliable operation in demanding industrial environments, providing consistent power regulation with minimal noise and ripple across various load conditions.
XP POWER JTK2024S05 High-Performance Power Module Specifications:
- Input Voltage Range: 9-36 VDC (JTK15), 18-75 VDC (JTK20)
- Input Current: 20 mA pk-pk (JTK15), 30 mA pk-pk (JTK20)
- Operating Temperature: -40°C to +100°C
- Maximum Capacitive Load: 375 kHz typical switching frequency
- Isolation Voltage: 1600 VDC input to output and case
- Efficiency: up to 89%
- Output Voltage: 3.3 V, 5 V, 12 V, 15 V, 5 V @ +6.2 V, 12 V @ +15 V, 15 V @ +18 V
- Line Regulation: 1% max, ±0.02%/°C max temperature coefficient
- Load Regulation: 0.5% max for single, 1.0% max dual outputs
- Protection: Overload, overvoltage, short circuit with hiccup mode, auto recovery
- Ripple & Noise: 100 mV pk-pk, 20 MHz bandwidth
- MTBF: 560,000 hours per MIL-STD-217F
- Dimensions: 1x1 inches, case temperature up to +105°C
- Certifications: UL60950-1, CAN/CSA, UL62368-1
- EMC Compliance: EN55022 Level A, EN61000-4-2/3/4/6/8
Buy the Power Supply Series JTK: JTK2024S05
Order the high-efficiency power module series JTK2024S05 online today to ensure reliable power regulation for industrial, automation, or control systems. This compact device delivers up to 89% efficiency, supporting wide input ranges and providing 1600 VDC isolation. Its rugged construction withstands temperatures from -40°C to +100°C, featuring overload, overvoltage, and short circuit protections with auto recovery. Ideal for DC/DC conversions, power management, and demanding environments, this module guarantees steady output with minimal noise, ensuring your devices operate smoothly and efficiently over time.
Get Power Supply Series JTK2024S05 today—built for high efficiency and reliable industrial power management.
Frequently Asked Questions
Where can I buy XP POWER JTK2024S05?
You can click on the BUY or RFQ button to purchase JTK2024S05 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part JTK2024S05?
You can download the JTK2024S05 datasheet or visit the XP POWER website for support.
Who is the manufacturer of JTK2024S05?
XP POWER
