XP POWER ITQ2415SA Isolated DC-DC Converter
The ITQ series is a compact 6W isolated DC-DC converter offering regulated single and dual outputs with a wide 4:1 input voltage range from 18V to 75V. It features 1500V DC isolation, operates efficiently from -40°C to 100°C with natural convection cooling, and requires no minimum load. Key features include remote on/off control, short circuit protection, and high efficiency up to 87%. The SIP 8 package ensures compactness, making it ideal for industrial, sensing, and instrumentation applications requiring reliable power conversion with high isolation and temperature tolerance.
XP POWER ITQ2415SA Isolated DC-DC Converter Specifications:
- Output Power: 6 Watts
- Input Voltage Range: 18V to 75V DC
- Input Voltage Nominal: 24V
- Input Surge Voltage: 50V DC for 100ms
- Output Voltage: 3.3V to 24V DC (see models)
- Output Accuracy: ±1%
- Line Regulation: 2-5%
- Load Regulation: 5-10%
- Ripple & Noise: 5 mV pk-pk, 20 MHz bandwidth
- Efficiency: Up to 87%
- Isolation Voltage: 1500V DC (add -H for 3000VDC option)
- Operating Temperature: -40°C to +100°C
- Humidity: 5% RH, non-condensing
- Case: SIP 8 Package
- Cooling: Natural convection
- Dimensions: 0.86 x 0.36 x 0.44 inches (21.9 x 9.2 x 11.1 mm)
- Remote On/Off: Yes, turns off at 2-4mA applied
- Certifications: UL, CSA safety approved
- Short Circuit Protection: Continuous with auto recovery
- Switching Frequency: 580 kHz
- Weight: Approximately 4.8 grams
Buy the XP Power Series ITQ Isolated DC-DC Converter: ITQ2415SA
Experience reliable power conversion with the XP Power ITQ Series isolated DC-DC converters. Designed with a compact SIP 8 package, they deliver up to 6W of regulated power with a wide input voltage range of 18V to 75V. Features include 1500V DC isolation, no minimum load required, remote on/off, and high efficiency up to 87%. Operating temperatures span from -40°C to 100°C, making them ideal for industrial, sensing, and instrumentation applications. Trust XP Power for durable, safe, and efficient power solutions available for convenient online purchase.
Get XP Power ITQ2415SA today—built for precision, high efficiency, and reliable isolation in industrial and sensing applications.
