XP POWER ITQ4812SA Industrial DC-DC Power Module
The ITQ4812SA is a compact, fully regulated 6-watt DC-DC power converter with a wide input voltage range of 18 to 75 VDC and an isolated 3000 VDC option. It features high efficiency up to 87%, no minimum load requirement, and failsafe short-circuit protection. Designed for industrial automation, telecommunications, and control systems, its small footprint (0.86 x 0.36 x 0.44 inches) and natural convection cooling make it ideal for space-constrained environments. Operating temperature ranges from -40°C to +100°C, ensuring reliability across demanding applications.
XP POWER ITQ4812SA Industrial DC-DC Power Module Specifications:
- Input Voltage Range: 18 to 75 VDC, 24 Vnominal, surge up to 50 V for 100 ms for 24 V models, 700 VDC for 100 ms for 48 V models
- Output Voltage: 3.3V, 5V, 9V, 12V, 15V, 25V, 212V, 215V (see models)
- Output Current: Ranges from 150 mA to 2250 mA depending on model
- Efficiency: Up to 87%
- Isolation: Input to Output 7500 VDC, optional 3000 VDC with ‘H’ suffix
- Ripple & Noise: 75 mV peak-to-peak at 20 MHz bandwidth
- Temperature Range: -40°C to +100°C operating, -55°C to +125°C storage
- Dimensions: 0.86 x 0.36 x 0.44 inches (21.9 x 9.2 x 11.1 mm)
- Operating Humidity: 5% RH non-condensing
- Isolation Resistance: 10² Ω
- Switching Frequency: 380 kHz
- MTBF: 2.8 million hours
- Construction: Natural convection cooling
- Certifications & Compliance: EN61000-4 immunity standards, conducted and radiated immunity, ESD, EFT, surge protection
Buy the Buy XP Power ITQ4812SA Part Number ITQ4812SA Online
Purchase the XP Power ITQ4812SA series 6-watt DC-DC converter online today. Its compact size, high efficiency up to 87%, wide input voltage range, and 3000 VDC isolation make it ideal for industrial automation, telecommunications, and control applications. With no minimum load required and robust short-circuit protection, this converter ensures reliable operation in demanding environments. Order now to upgrade your power solutions with a trusted, regulation-proven device that offers durability, space-saving design, and easy integration for various technical needs.
Order your XP Power ITQ4812SA series 6W DC-DC converter today and ensure reliable power delivery with high efficiency and wide input range for industrial systems.
Frequently Asked Questions
Where can I buy XP POWER ITQ4812SA?
You can click on the BUY or RFQ button to purchase ITQ4812SA from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITQ4812SA?
You can download the ITQ4812SA datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITQ4812SA?
XP POWER
