XP POWER ITV2412SA DC-DC Converter
The ITV series of unregulated DC power modules offers high temperature operation from -40°C to +105°C, dual and single outputs, and robust encapsulation. With features like short circuit protection, high isolation of 3000 VDC, and efficiency up to 81%, these modules are cost-effective and reliable for industrial applications. The compact SIP7 package measures approximately 0.76 x 0.24 x 0.39 inches, suitable for space-constrained environments. Designed for continuous full load at 95°C ambient, they are ideal for rugged industrial power supply needs.
XP POWER ITV2412SA DC-DC Converter Specifications:
- Input Voltage Range: 10.8 to 13.2 VDC (12V nominal), 21.6 to 26.4 VDC (24V nominal)
- Output Voltage: 5V, 12V, 15V, 25V, 26V, 22V options with specific current ratings
- Output Current: Up to 416 mA depending on model; minimum load 10%
- Efficiency: Up to 81% at full load
- Isolation: 3000 VDC, functional
- Operating Temperature: -40°C to +105°C, derating from 100% load at +95°C to 90% at +105°C
- Power Density: Approximately 14 W/in³
- Package: SIP7, dimensions approx. 0.76 x 0.24 x 0.39 inches (19.5 x 6.0 x 10.0 mm)
- Protection: Short circuit, full load at high temperatures, robust encapsulation
- Certifications: UL, CE, UKCA compliant
- Soldering: Max temperature 260°C, case-mounted
- Weight: ~2.4 grams
- Mechanical: Pin diameter 0.020 ± 0.002 inches, pitch tolerance ±0.014 inches
Buy the XP Power ITV2412SA – Reliable DC-DC Converter for Industrial Applications
Purchase the XP Power ITV2412SA online today for high-performance, unregulated power conversion suitable for industrial systems. This compact module features a SIP7 package measuring approximately 0.76 x 0.24 x 0.39 inches, supporting a wide input voltage range of 10.8 to 13.2 VDC or 21.6 to 26.4 VDC. It delivers reliable output currents up to 416 mA with efficiency up to 81%. Designed for high-temperature operation from -40°C to +105°C, it includes short circuit protection, 3000 VDC isolation, and robust encapsulation, ensuring durability and performance for demanding applications.
Get XP Power ITV2412SA today—built for precision and long-lasting durability in rugged industrial environments.
Frequently Asked Questions
Where can I buy XP POWER ITV2412SA?
You can click on the BUY or RFQ button to purchase ITV2412SA from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITV2412SA?
You can download the ITV2412SA datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITV2412SA?
XP POWER
