XP POWER ITQ4815SA DC-DC Converter
The ITQ series is a compact and reliable 6W isolated DC-DC converter offering regulated single and dual outputs with a broad 4:1 input voltage range. Designed for industrial and automation applications, it operates efficiently from -40°C to 100°C and provides 1500VDC isolation for safety and noise filtering. The module features no minimum load requirement, remote on/off control, and short circuit protection, ensuring stable operation across various environments. UL62368-1 safety approval and high efficiency make it ideal for demanding power management tasks in compact spaces.
XP POWER ITQ4815SA DC-DC Converter Specifications:
- Input Voltage Range: 18V to 75VDC, 24V nominal, Surge 50VDC for 100ms, reflected ripple 20,740 mA pk-pk
- Output Voltage: 3.3V, 5V, 12V, 15V, 24V; adjustable within typical specifications
- Output Power: 6W, regulated single or dual outputs
- Isolation: 1500VDC, optional 3000VDC with suffix '-H'
- Efficiency: Up to 87%, typical at 87%
- Operating Temperature: -40°C to +100°C, derating at higher temperatures
- Mechanical: SIP 8 package, dimensions approximately 0.86 x 0.36 x 0.44 inch (21.9 x 9.2 x 11.1 mm)
- Protection: Short circuit, no minimum load required, remote on/off control capable of turning off with 2-4 mA applied
- Certifications: UL60950-1, UL62368-1, CSA C22.2 No. 60950-1, No. 62368-1
- Additional: Tightly regulated output, high efficiency, dielectric isolation, natural convection cooling
Buy the XP Power ITQ4815SA – Reliable Power Conversion for Industrial Applications
Purchase the XP Power ITQ4815SA series DC-DC converter online today and benefit from a compact, highly efficient power solution essential for industrial automation, control systems, and power management projects. Featuring fully regulated outputs, excellent thermal performance, and safety approvals, this 6W module offers reliable operation over wide temperature ranges. Its remote on/off feature and no minimum load requirement simplify integration. Get your reliable power conversion solution now to enhance your system’s performance and ensure safety compliance in demanding environments.
Order your XP Power ITQ4815SA series high-efficiency DC-DC converter today and ensure stable, safe power management for your industrial systems.
Frequently Asked Questions
Where can I buy XP POWER ITQ4815SA?
You can click on the BUY or RFQ button to purchase ITQ4815SA from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITQ4815SA?
You can download the ITQ4815SA datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITQ4815SA?
XP POWER
