XP POWER IH0524D Dual Output Power Module
This dual output unregulated power supply module features SIP or DIP packages, offering 1000 VDC isolation with options for 3000-6000 VDC isolation. It boasts an MTBF exceeding 1.1 million hours, ensuring high reliability for critical systems. Operating efficiently within a temperature range of -40°C to +85°C, it is suitable for various industrial applications requiring stable voltage outputs. Designed for robustness, it integrates safety features compliant with CE and UKCA standards, making it ideal for demanding environments, providing dependable power for essential electronic systems and automation equipment.
XP POWER IH0524D Dual Output Power Module Specifications:
- Input Voltage Range: Not specified
- Input Reflected Ripple Current: 20mA pk-pk through 12uH inductor, 5Hz to 20 MHz
- Input Reverse Voltage Protection: None
- Input Filter: Capacitor
- Output Voltage: 3.3V, 5V, others (see table)
- Minimum Load: Not specified
- Line Regulation: 1.2%/1% AVin
- Load Regulation: 10% 20-100% load change
- Ripple & Noise: 43% maximum, 75 mV pk-pk max, 20 MHz bandwidth
- Temperature Coefficient: 0.02%/°C
- Maximum Capacitive Load: 220 UF
- Cross Regulation: See table
- Efficiency: 43%
- Isolation Voltage: Nominal 1.2kV DC, optional 3.0kV-6.0kV DC
- Isolation Resistance: >1.1 MOhms
- Isolation Capacitance: 60 pF typical
- MTBF: >1.1 million hours according to MIL-HDBK-217F
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +125°C
- Case Temperature: Max 100°C
- Cooling: Convection-cooled
- Safety Agency Compliance: CE & UKCA
Buy the Buy Power Supply Components Part Number IH0524D Online
Discover the high-reliability dual output power module designed for critical electronic systems. Featuring up to 6000 VDC isolation, an MTBF exceeding 1.1 million hours, and operation from -40°C to +85°C, this industrial-grade component ensures stable voltage supply with high safety standards. Its robust construction, efficient performance, and compliance with CE and UKCA standards make it ideal for automation, instrumentation, and control applications where dependable power is essential. Order online today for swift delivery and seamless integration into your system.
Buy Power Supply IH0524D now and experience unmatched reliability and performance for critical electronic systems with high dielectric isolation.
Frequently Asked Questions
Where can I buy XP POWER IH0524D?
You can click on the BUY or RFQ button to purchase IH0524D from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part IH0524D?
You can download the IH0524D datasheet or visit the XP POWER website for support.
Who is the manufacturer of IH0524D?
XP POWER
