XP POWER ECL15US03P Power Supply
This power supply features an ultra-compact design with options for single, dual, and triple output configurations. It is available in open-frame PCB and chassis mount styles, as well as encapsulated PCB and chassis mount versions. The device consumes less than 0.3W of no-load input power and supports peak load capacity. Built with Class II construction, it is suitable for power management and industrial applications.
XP POWER ECL15US03P Power Supply Specifications:
- Input Voltage: 85-264 VAC, 120-370 VDC
- Frequency: 47-63 Hz
- No Load Input Power: <0.3 W
- Output Voltage Trim: +5% on output 1 only, tracking on multiple outputs
- Efficiency: see tables
- Isolation: 3000 VAC Input to Output
- Switching Frequency: 70 KHz typical
- Peak Load Capability: Yes
- Operating Temperature: -20 °C to +70 °C, derate linearly from 100% at +50 °C to 50% at +70 °C
- Vibration: 2g, 10 Hz to 500 Hz, 10 mins/cycle
- EMC Compliance: EN55032 level B, EN61000-3-2, EN61000-4 series
- Safety: IEC60950-1:2005 Ed 2 / IEC62368-1:2014, UL 62368-1
Buy the Xppower Series ECL Power Supply: ECL15US03
Order the Xppower ECL15US03 power supply online today for reliable performance and robust construction suitable for industrial, automation, and power management applications. Its compact size, low no-load power consumption, and peak load capacity make it ideal for controlling power efficiently. Easily integrate the power supply into various systems with open-frame or encapsulated options, ensuring safety and compliance. Take advantage of fast shipping and excellent customer support by purchasing online now.
Get Xppower ECL15US03 today—built for precision and long-lasting durability in industrial power management.
