XP POWER JTE0624S24 DC-DC Power Converter
The JTE0624S24 power supply is a high-performance, compact DC-DC converter designed for industrial applications requiring reliable power conversion. It features a 4:1 input range, operating from 9-36 VDC, and offers a 24V output with ±2% accuracy. Built with advanced Pi network filtering, it includes robust protection features such as overload, short circuit, and overvoltage protections. Suitable for demanding environments, it operates between -40°C to +100°C, providing high efficiency, galvanic isolation up to 1500 VDC, and a MTBF of over 800,000 hours. Its rugged design supports both plastic and optional metal cases, making it ideal for industrial automation, control systems, and telecommunications.
XP POWER JTE0624S24 DC-DC Power Converter Specifications:
- Input Voltage Range: 9-36 VDC
- Input Filter: Pi network
- Input Surge: 50VDC for 100 ms (24V models), 100VDC for 100 ms (48V models)
- Input Reflected Ripple: 20 mA pk-pk through 12 HH inductor and 4.7 UF capacitor
- Output Voltage: 24 V (±2%), dual output models ±2%
- Output Voltage Balance: See table
- Initial Set Accuracy: ±2% max
- Minimum Load: No minimum load required
- Line Regulation: 1.2% max for single, 5% for dual
- Load Regulation: 5% max from 10-100% load
- Cross Regulation: ±5%
- Start Up Delay: 20 ms typical
- Ripple & Noise: 80 mV pk-pk (100 mV for D24 models), 20 MHz bandwidth
- Transient Response: <3% deviation, recovery within 300 ps for 25% load change
- Overload Protection: Trip & restart (Hiccup mode), auto recovery
- Short Circuit Protection: Yes
- Maximum Capacitive Load: 135% - 185% of full load
- Temperature Range: -40°C to +100°C (derate from 100% load at +60°C to no load at +100°C)
- Operating Temperature: -40°C to +100°C
- Case Temperature: Max +100°C
- Storage Temperature: -85°C to +125°C
- Cooling Method: Natural convection
- Operating Humidity: Up to 95%, non-condensing
- Isolation Voltage: 1500 VDC (up to 3000 VDC optional)
- Isolation Capacitance: 1000 pF typical input to output
- Switching Frequency: 330 kHz typical
- Power Density: Refer to datasheet
- MTBF: Over 800,000 hours at 25°C (MIL-HDBK-217F)
- EMC & Immunity: EN55022 class A, EN61000-4 series compliance, up to 8 KV air discharge
- Safety: UL60950-1, CSA C22.2 No.60950-1
- Dimensions: Plastic case approx. 0.90 x 1.25 inches; optional metal case available
Buy the Buy Power Supply DC-DC Converter Part Number JTE0624S24 Online
Order the JTE0624S24 DC-DC power converter online today to benefit from high efficiency, robust protection features, and a wide operating temperature range. Perfect for industrial automation, control systems, and demanding environments requiring reliable power conversion. This high-quality power supply offers strong galvanic isolation, a compact design in both plastic and metal cases, and a MTBF of over 800,000 hours, ensuring longevity and minimal downtime. Enhance your project’s performance by sourcing this essential power supply directly from authorized distributors today.
Buy Power Supply JTE0624S24 now and experience unmatched reliability and performance for industrial and automation applications.
Frequently Asked Questions
Where can I buy XP POWER JTE0624S24?
You can click on the BUY or RFQ button to purchase JTE0624S24 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part JTE0624S24?
You can download the JTE0624S24 datasheet or visit the XP POWER website for support.
Who is the manufacturer of JTE0624S24?
XP POWER
