XP POWER SR05S05 DC-DC Converter
The SR series from XP Power offers compact, fixed output DC to DC converters in a 3-pin SIP package, with wide input voltage range, high efficiency up to 97%, and continuous short-circuit protection. These non-isolated power modules are pin-compatible with LM78MXX regulators, making them ideal for industrial, medical, and power management applications. Operating over -40°C to +85°C, they provide reliable performance with low noise, high efficiency, and robust short-circuit and thermal protections. Their small form factor and wide input range ensure versatility across demanding electronic systems.
XP POWER SR05S05 DC-DC Converter Specifications:
- Input Voltage Range: 50 V to 150 V, with external filtering recommended
- Input Current: 15 mA at maximum input voltage
- Input Ripple: 35-40 mA pk-pk, filtered by external capacitor
- Output Voltage: 5 V with a load of 70 mA
- Maximum Output Current: 70 mA
- Load Regulation: 0.6% from 10% to 100% load
- Line Regulation: +0.5% max
- Setpoint Accuracy: ±2%
- Efficiency: up to 97%
- Operating Temperature Range: -40°C to +85°C for SR05, -40°C to +60°C for SR10
- Switching Frequency: approximately 330 kHz
- Maximum Capacitive Load: 220 µF
- Short Circuit Protection: Indefinite with automatic recovery
- Isolation Voltage: Non-isolated
- Package Style: 3-pin SIP
- Dimensions: Compact form factor suitable for tight spaces
- MTBF: over 4.5 million hours at 25°C per MIL-HDBK-217F
- Cooling: Convection-cooled
- Safety Approvals: CE & UKCA compliant
- Temperature Coefficient: +0.02%/°C
- Case Temperature Maximum: +100°C
- Storage Temperature Range: -40°C to +125°C
Buy the XP Power Series SR DC-DC Converter: SR05S05
Purchase the XP Power Series SR05S05 DC-DC converter online today and enjoy the benefits of a compact, high-efficiency power solution. With up to 97% efficiency, continuous short-circuit protection, and reliable operation within a broad temperature range, this converter is perfect for demanding industrial, medical, and electronic applications. Its small size and robust performance make it an ideal choice for space-constrained projects that require stable power. Secure your supply chain by ordering online now and ensure your systems operate seamlessly and efficiently.
Order your XP Power Series SR05S05 high-efficiency switching regulator today and ensure reliable power supply for your industrial and electronic systems.
