XP POWER SR05S1V5 Switching Regulator
The SR Series is a compact 3-pin SIP switching regulator designed for high-efficiency power conversion with up to 97% efficiency. It features a wide input voltage range suitable for various applications, operates from -40°C to +85°C (SR05S1V5: -40°C to +60°C), and provides continuous short-circuit protection with automatic recovery. This non-isolated regulator supports output currents up to 1.5A, with low ripple and noise of 60mV pk-pk at 20 MHz bandwidth. It complies with safety standards CE and UKCA, making it ideal for critical electronic systems requiring reliable power supplies.
XP POWER SR05S1V5 Switching Regulator Specifications:
- Input Voltage Range: 15-18 VDC
- Input Current: varies with load
- Output Voltage: 1.5 V (SR05S1V5)
- Maximum Load: 1.5A
- Line Regulation: +0.5% max
- Load Regulation: 0.6% from 10% to 100% load
- Ripple & Noise: 60mV pk-pk at 20 MHz bandwidth
- Operating Temperature: -40°C to +85°C (SR05S1V5: -40°C to +60°C)
- Efficiency: up to 97%
- Switching Frequency: approx. 330 kHz
- Package Style: 3-pin SIP
- Isolation Voltage: Non-isolated
- MTBF: >4.5 million hours at 25°C
- Safety & Standards: CE & UKCA compliant
- Cooling: Convection-cooled
- Storage Temperature: -40°C to +125°C
Buy the Buy Power Solutions Switching Regulator Part Number SR05S1V5 Online
Purchase the Power Solutions SR05S1V5 switching regulator online to ensure your electronic devices operate efficiently with up to 97% efficiency. This compact, 3-pin SIP device provides a wide input voltage range and reliable operation from -40°C to +85°C. Its features include continuous short-circuit protection with automatic recovery, high efficiency, low ripple and noise, and compliance with CE and UKCA standards. Ideal for powering sensitive, critical systems requiring stable and secure power delivery in various industrial and electronic applications.
Buy Power Solutions SR05S1V5 now and experience unmatched reliability and high efficiency in power regulation for critical electronic systems.
Frequently Asked Questions
Where can I buy XP POWER SR05S1V5?
You can click on the BUY or RFQ button to purchase SR05S1V5 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part SR05S1V5?
You can download the SR05S1V5 datasheet or visit the XP POWER website for support.
Who is the manufacturer of SR05S1V5?
XP POWER
