BROADCOM AEAT6010A06 Magnetic Encoder
The magnetic encoder provides absolute angular detection with a resolution of 0.35°, suitable for precise rotary measurement in industrial applications. Its contactless sensing technology ensures reliability and durability across operating temperatures from -40°C to 125°C. The device features a compact design with a 6mm shaft diameter, mechanical speed up to 12,000 rpm, and serial SSI output for easy integration into control systems. It’s RoHS compliant and ideal for flow meters, knob controls, and rotary encoders, offering robust performance in demanding environments.
BROADCOM AEAT6010A06 Magnetic Encoder Specifications:
- Resolution: 10 bits
- Angular resolution: 0.35°
- Supply Voltage: 5V
- Output: Serial SSI
- Operating Temperature: -40°C to 125°C
- Maximum Mechanical Speed: 12,000 rpm
- Shaft Diameter: 6 mm ±0.01 mm
- Shaft Length: 8.5 mm +1.0 mm
- Shaft TIR: 0.05 mm
- Shaft Axial Play: +0.08 mm
- Package Thickness: 2 mm
- Mounting: M2x0.4x8 screw, recommended torque 0.6 lb.inch
- Connection: VDD, GND, Output Data, Serial Clock, Chip Select
- Linearity: INL ≤ 0.81°, DNL ≤ 0.176°
- EMC Immunity: IEC/EN 61000-4-2, 4-8, 4-97, 4-10
- Mechanical Durability: Vibration and Shock resistant
Buy the Avago Series AEAT Magnetic Encoder: AEAT6010A06
Experience the reliability and accuracy of the Magnetic Encoder for industrial applications with 10-bit resolution and serial SSI output. Designed to operate in harsh conditions from -40°C to 125°C, this contactless device ensures precise angular detection for flow meters, rotary encoders, and control knobs. Its compact design with a 6mm shaft diameter and mounting compatibility makes installation straightforward. Purchase the Avago AEAT6010A06 online today and enhance your angular measurement systems with a high-performance, durable encoder built for demanding environments.
Get Avago AEAT6010A06 today—built for precision and long-lasting durability in angular detection systems.
