BROADCOM HLMPEG1AZ10DD High Brightness Red LED
The HLMP-EG1A-Z10DD is an extra high brightness red LED lamp made of AlInGaP technology. It offers superior light output, ensuring excellent readability in sunlight, and is highly reliable. The LED utilizes advanced AlInGaP technology for stable light output over extended periods. Designed in a T-1-3/4 package with second-generation optics, it produces well-defined spatial radiation patterns at specific viewing angles. The lamp is crafted with an advanced optical-grade epoxy that provides excellent resistance to high temperatures and moisture, making it ideal for outdoor signal and signage applications. Its maximum junction temperature of +130°C allows for operation in bright sunlight. The epoxy includes UV-A and UV-B inhibitors to minimize long-term damage from sunlight exposure. Suitable for outdoor use, automotive signaling, LED lighting, and PCB assembly, it operates over a temperature range of -40°C to +100°C and offers high luminous output with robust moisture resistance.
BROADCOM HLMPEG1AZ10DD High Brightness Red LED Specifications:
- Package Type: T-1-3/4 (5mm) with second-generation optics
- Wavelength: 626nm (Red)
- Viewing Angles: 15°, 23°, 30° options available
- Maximum Junction Temperature: +130°C
- Operating Temperature Range: -40°C to +100°C
- Luminous Output: 12,000 to 21,000 mcd at 20mA
- Forward Voltage: 18V to 21V at 20mA
- Peak Wavelength: 634nm
- Thermal Resistance: 240°C/W junction to lead
- Body Material: Optical-grade epoxy with UV inhibitors
- Electrical Current: 50mA DC, 100mA peak, 30mA average
- Power Dissipation: 120mW
- Reverse Voltage: 5V
- RoHS Compliant, Lead-free
Buy the Avago HLMP-EG1A-Z10DD – Reliable Red LED for Industrial Applications
Purchase the Avago HLMP-EG1A-Z10DD high-brightness red LED online today and ensure optimal visibility for outdoor signs, automotive signals, and LED lighting. With advanced AlInGaP technology, it provides stable light output and excellent moisture resistance. Designed for durability in harsh environments, this LED operates up to +130°C junction temperature, making it perfect for outdoor applications requiring high reliability and brightness. Enjoy fast delivery and quality assurance by buying directly online from authorized distributors for seamless integration into your projects.
Order your Avago HLMP-EG1A-Z10DD high-brightness LED today and enhance your outdoor signaling and signage projects with dependable quality.
Frequently Asked Questions
Where can I buy BROADCOM HLMPEG1AZ10DD?
You can click on the BUY or RFQ button to purchase HLMPEG1AZ10DD from an authorized BROADCOM distributor.
How do I troubleshoot issues or seek technical support for part HLMPEG1AZ10DD?
You can download the HLMPEG1AZ10DD datasheet or visit the BROADCOM website for support.
Who is the manufacturer of HLMPEG1AZ10DD?
BROADCOM
