KEYSIGHT TECHNOLOGIES N1913A RF Power Meter
The Keysight N1913A power meter is a single-channel device designed for precise RF average power measurements across a frequency range of 9 kHz to 110 GHz on compatible sensors. It features a color LCD display, USB and LAN interfaces, and supports automation with external trigger options. With measurement speeds up to 400 readings/sec and a three-year warranty, it is ideal for high-performance testing in wireless, radar, and RF lab environments, replacing older models with enhanced features and compatibility.
KEYSIGHT TECHNOLOGIES N1913A RF Power Meter Specifications:
- Frequency range: 9 kHz to 110 GHz
- Power range: -70 dBm to +44 dBm (100 pW to 25 W)
- Measurement speed: Up to 400 readings/sec with E-Series sensors
- Absolute accuracy: + 0.02 dB (logarithmic), + 0.5% (linear)
- Relative accuracy: + 0.04 dB (logarithmic), + 1% (linear)
- Display units: Watts, dBm, Percent, dB
- Display resolution: 1.0, 0.1, 0.01, 0.001 dB or 1-4 significant digits
- Dimensions: 212.6 W x 88.5 H x 348.3 D mm
- Weight: 3.6 kg (net), 8.2 kg (shipping)
- Interfaces: GPIB, USB 2.0, LAN
- Environmental: Operating at 0°C to 55°C, humidity up to 95%
- Power supply: 90-264 VAC, Battery operation up to 6 hours
- Warranty: 3-year return-to-keysight warranty
Buy the Buy Keysight N1913A Power Meter Part Number N1913A Online
Purchase the Keysight N1913A power meter online and enhance your wireless and RF testing capabilities. Featuring a high-resolution color LCD, measurement speeds up to 400 readings/sec, and industry-standard interfaces like USB and LAN. Its wide frequency range from 9 kHz to 110 GHz makes it suitable for diverse applications including radar, 5G, and lab measurements. Backed by a three-year warranty, this instrument ensures accurate and reliable power measurements, supports automation, and replaces older models with superior performance for professional RF testing.
Order your Keysight N1913A RF power meter today and achieve high-speed, accurate RF measurements with industry-leading features and reliable performance.
