MEAN WELL HLG120H12B LED Driver
The HLG-120H series is a high-efficiency 120W AC/DC LED driver with dual output modes of constant voltage and constant current, suitable for indoor and outdoor lighting applications. Operating from 90 to 305VAC, it features models with rated voltages between 12V and 54V, and achieves up to 93.5% efficiency. Its robust metal housing with IP67/IP65 ratings allows for wet or damp environments. With built-in dimming options, active PFC, and a lifetime over 62,000 hours, it is ideal for LED street, high-bay, greenhouse, fishing, park, and other lighting solutions.
MEAN WELL HLG120H12B LED Driver Specifications:
- Rated power: 120W
- Input voltage: 90~305VAC
- Rated output voltages: 12V to 54V
- Rated current: 10A to 2.3A depending on model
- Ripple & Noise: Max 200mVp-p
- Efficiency: Up to 93.5%
- Protection: Over voltage, over temperature, short circuit, over current
- Ingress Protection: IP67/IP65 for outdoor/indoor use
- Operating temperature: -40°C to +80°C
- Dimensions: 220mm x 68mm x 38.8mm
- Lifetime: >62,000 hours
- Certifications: UL, CSA, EN/AS/NZS, BIS, EAC, KC
Buy the Buy MEAN WELL HLG120H Series 120W Constant Voltage + Constant Current LED Driver Online
Enhance your lighting projects with the MEAN WELL HLG120H series LED driver. Offering up to 93.5% efficiency, IP67/IP65 ratings, adjustable dimming, and over 62,000 hours lifetime. Perfect for outdoor and indoor applications including street lighting, high bays, and greenhouse illumination. Easy to install, reliable, and certified to meet international safety standards. Get your high-quality LED driver online today and ensure your lighting systems operate smoothly, efficiently, and durably, backed by a 7-year warranty for peace of mind.
Order your MEAN WELL HLG120H series 120W LED driver today and equip your lighting system with reliable, high-performance power solutions.
Frequently Asked Questions
Where can I buy MEAN WELL HLG120H12B?
You can click on the BUY or RFQ button to purchase HLG120H12B from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part HLG120H12B?
You can download the HLG120H12B datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of HLG120H12B?
MEAN WELL
