MOLEX 09507101 KK 3.96mm Crimp Terminal Housing
The MOLEX 09-50-7101 KK 3.96mm Crimp Terminal Housing is a versatile component within the KK Interconnect System. Designed for power and wire-to-board applications, this housing accommodates a maximum of 10 circuits and is constructed from natural nylon resin, ensuring robust performance. It is compatible with a range of KK 396 headers and crimp terminals, making it suitable for diverse industrial and commercial applications. Its compact design and ease of use contribute to efficient assembly and reliable connections.
MOLEX 09507101 KK 3.96mm Crimp Terminal Housing Specifications:
- circuits_maximum: 10
- color_resin: Natural
- flammability: 94V-2
- gender: Receptacle
- material_resin: Nylon
- number_of_rows: 1
- packaging_type: Bag
- pitch_mating_interface: 3.96mm
- temperature_range_operating: See Product Specification
- net_weight: 2.560/g
- upc: 800753640795
- engineering_number: 2139-10C
- series: 2139
- application: Power, Wire-to-Board
- mates_with: KK 396 Headers:41771, 41772, 41791, 41792, 42491, 42492, KK 396 Breakaway Headers:41661, 41662, 41671, 41672
- use_with: 2478 Crimp Terminals for 18-24 AWG, 2578 Crimp Terminals for 22-26 AWG
- halogen_free_status: Low-Halogen
- reach_svhc_compliance: Not Contained Per ED/88/2018
Buy the 09-50-7101 MOLEX KK 396 Crimp Terminal Housing | myMectronic
Purchase the MOLEX 09-50-7101 KK 3.96mm Crimp Terminal Housing securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 09507101?
You can click on the BUY or RFQ button to purchase 09507101 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 09507101?
You can download the 09507101 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 09507101?
MOLEX
