MOLEX 1054291106 Nano-Fit Power Connector
Nano-Fit vertical header connectors are surface-mount, dual-row components with 2.50mm pitch, six circuits, and 0.76um tin plating. Designed for power wire-to-board applications, these connectors are glow-wire capable, black in color, and rated for 6.5A and 250V AC. They feature robust brass metal with gold plating for mating contacts, and liquid crystal polymer resin for insulation. Suitable for high-reliability electronic assemblies, they support up to 50 mating cycles, operate within -40°C to +115°C, and are RoHS compliant. Ideal for compact, surface-mount power connections in various electronic devices.
MOLEX 1054291106 Nano-Fit Power Connector Specifications:
- Pitch: 2.50mm for mating and termination interfaces
- Number of Circuits: 6 per connector
- Color - Resin: Black
- Material - Metal: Brass
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Material - Resin: Liquid Crystal Polymer
- Durability: Up to 50 mating cycles
- Current - Maximum per Contact: 6.5A
- Voltage - Maximum: 250V AC (RMS)
- Operating Temperature: -40°C to +115°C
- Net Weight: 0.943g
- Orientation: Vertical
- PCB Thickness - Recommended: 1.60mm
- Packaging Type: Embossed Tape on Reel
- Glow-Wire Capable: Yes
- RoHS Compliance: Yes
- Low-Halogen: Yes
Buy the Buy Molex Nano-Fit Power Connectors Part Number 1054291106 Online
Purchase the Molex Nano-Fit Power Connector, a compact and reliable surface-mount component featuring 2.50mm pitch, 6 circuits, glow-wire capability, and rated for 6.5A at 250V. Made with durable brass and gold plating, combined with high-temperature resistant liquid crystal polymer insulation, it ensures long-lasting performance in electronic assemblies. Suitable for power applications requiring high durability, it supports up to 50 mating cycles, operates within -40°C to +115°C, and is RoHS compliant, making it an ideal choice for modern electronic systems.
Get Molex 1054291106 today—built for power reliability with surface-mount design and dual-row circuits.
Frequently Asked Questions
Where can I buy MOLEX 1054291106?
You can click on the BUY or RFQ button to purchase 1054291106 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 1054291106?
You can download the 1054291106 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 1054291106?
MOLEX
