MOLEX 2121320002 Pico-EZmate Receptacle Housing
The MOLEX 212132-0002 Pico-EZmate Plus Receptacle Housing is a compact wire-to-board connector solution ideal for applications requiring high-density connections in limited spaces. Constructed from durable polyamide, this housing provides reliable insulation and mechanical protection. Its 1.00mm pitch and 2-circuit design make it suitable for signal transmission in various electronic devices, including consumer electronics, industrial equipment, and automotive applications. The polarized design and locking mechanism ensure secure and reliable mating with compatible PCB headers.
MOLEX 2121320002 Pico-EZmate Receptacle Housing Specifications:
- circuits_maximum: 2
- color_resin: Black
- glow_wire_capable: No
- keying_to_mating_part: None
- lock_to_mating_part: Yes
- material_resin: Polyamide
- net_weight_mg: 7.100
- number_of_rows: 1
- packaging_type: Bag
- pitch_mating_interface: 1.00mm
- polarized_to_mating_part: Yes
- temperature_range_operating_c: -40 to +105
- upc: 193264124626
- series: 212132
- application: Signal, Wire-to-Board
- product_family: Crimp Housings
- mates_with: Pico-EZmate Plus PCB Header 212134
Buy the 212132-0002 MOLEX Pico-EZmate Receptacle Housing | myMectronic
Purchase the MOLEX 212132-0002 Pico-EZmate Receptacle Housing securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 2121320002?
You can click on the BUY or RFQ button to purchase 2121320002 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2121320002?
You can download the 2121320002 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2121320002?
MOLEX
