MOLEX 39299246 Power Connector
The Mini-Fit Jr. Vertical Header with a 4.20mm pitch is a reliable power connector designed for wire-to-board applications. It features dual rows and 24 circuits, with snap-in plastic pegs for secure PCB locking. Made from halogen-free, low-halogen resin, it supports operating temperatures from -40°C to +105°C and provides a maximum current of 9A per contact at 600V. Compatible with standard Mini-Fit female terminals, it is ideal for applications requiring durable, space-efficient, and RoHS-compliant power connections in industrial and electronic systems.
MOLEX 39299246 Power Connector Specifications:
- Pitch: 4.20mm
- Number of Circuits: 24
- Material: Halogen-free, low-halogen resin
- Plating: Mating and termination minimum 0.889um
- Operating Temperature: -40°C to +105°C
- Max Current per Contact: 9A
- Max Voltage: 600V
- Insertion Force: Standard with snap-in plastic lock
- PCB Thickness: 1.60mm
- Termination Style: Through Hole
- Mating Interface: 4.20mm pitch, polarized, shrouded
- Durability: Rated for multiple mating cycles
- Certification: UL, CSA, REACH SVHC compliant
- Packaging: Tray
- Physical dimensions: 3.50mm height, stackable design not supported
- Features: PCB retention, fully shrouded, non-stackable, surface-mount incompatible
Buy the Molex 0039299246 – Reliable Power Connector for Industrial Applications
Purchase the Molex 0039299246 power connector online today for a high-quality, RoHS-compliant, 24-circuit vertical header with a 4.20mm pitch. Its durable design supports up to 9A per circuit at 600V, making it ideal for industrial, automation, and electronics applications needing reliable wire-to-board power connections. With features like PCB retention, polarization, and a snap-in plastic lock, this connector ensures secure assembly and long-term performance. Shop now for efficient, space-saving power solutions with quick online ordering.
Order your Molex 0039299246 Series 5566 vertical power connector today and ensure dependable, high-current power connections for your industrial projects.
Frequently Asked Questions
Where can I buy MOLEX 39299246?
You can click on the BUY or RFQ button to purchase 39299246 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 39299246?
You can download the 39299246 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 39299246?
MOLEX
