MOLEX 5019400407 Pico-Clasp Wire-to-Board Connector
The MOLEX 501940-0407 Pico-Clasp wire-to-board connector is a compact and reliable solution for connecting wires to printed circuit boards. Designed with a 1.00mm pitch and a vertical orientation, this connector is ideal for applications where space is limited. It features 4 circuits and a surface mount design, ensuring ease of integration into various electronic assemblies. The connector's robust construction and secure locking mechanism provide a durable and dependable connection for a wide range of industrial and consumer electronics applications.
MOLEX 5019400407 Pico-Clasp Wire-to-Board Connector Specifications:
- Pitch - Mating Interface: 1.00mm
- Material - Resin: High Temperature Thermoplastic
- Mating Material - Plating: Tin
- Termination Material - Resin: High Temperature Thermoplastic
- Durability (mating cycles max): 30
- Current - Maximum per Contact: 1.0A
- Voltage - Maximum: 50V
- Mated Height: 7.30mm
- Material - Metal: Phosphor Bronze
- Plating min - Mating: 1.016µm
- Plating min - Termination: 1.016µm
- Number of Rows: 1
- Temperature Range - Operating: -40°C to +105°C
- Breakaway Circuits (Loaded): No
- Circuits (maximum): 4
- Guide to Mating Part: No
- Keying to Mating Part: No
- Lock to Mating Part: Yes
- Polarized to Mating Part: Yes
- Polarized to PCB: No
- Stackable: No
- Glow-Wire Compliant: No
- PCB Retention: Yes
- Net Weight: 121.700/mg
- Orientation: Vertical
- PCB Locator: No
- Packaging Type: Embossed Tape on Reel
- Termination Interface: Style: Surface Mount
Buy the 501940-0407 MOLEX Pico-Clasp Wire-to-Board Connector | myMectronic
Purchase the MOLEX 501940-0407 Pico-Clasp Wire-to-Board Connector securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 5019400407?
You can click on the BUY or RFQ button to purchase 5019400407 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 5019400407?
You can download the 5019400407 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 5019400407?
MOLEX
