MOLEX 5023820471 Wire-to-Board Connector
The 5023820471 is a 1.25mm pitch CLIK-Mate wire-to-board PCB receptacle designed for reliable electrical connections in compact electronic assemblies. Featuring a single row, vertical orientation, and gold plating, it supports up to 4 circuits for signal transfer. Crafted from high-temperature thermoplastic with gold over nickel plating on the contacts, this connector offers excellent durability with a maximum of 30 mating cycles. It operates within a temperature range of -40°C to +105°C, rated for 1.0A current and 50V AC/DC, ideal for space-constrained and high-performance electronic applications.
MOLEX 5023820471 Wire-to-Board Connector Specifications:
- Pitch - Mating Interface: 1.25mm
- Number of Circuits: 4
- Color - Resin: Natural
- Material - Metal: Copper Alloy
- Material - Plating Mating: Gold over Nickel
- Material - Plating Termination: Gold over Nickel
- Material - Resin: High Temperature Thermoplastic
- Durability: 30 mating cycles maximum
- Operating Temperature Range: -40°C to +105°C
- Current - Maximum per Contact: 1.0A
- Voltage - Maximum: 50V AC/DC
- Mated Height: 7.80mm
- Orientation: Vertical
- Termination Interface: Surface Mount
- Packaging: Embossed Tape on Reel
Buy the Buy Molex 5023820471 Part Number 5023820471 Online
Secure your electronic projects with the 5023820471 CLIK-Mate wire-to-board connector. Ideal for compact assemblies, it features gold-plated contacts, a 1.25mm pitch, and supports up to 4 circuits for reliable signal transfer. Made from high-temperature thermoplastic, the connector withstands operating temperatures from -40°C to +105°C and offers up to 30 mating cycles. Perfect for space-saving and high-performance applications, order online today for quick delivery and proven durability.
Buy Molex 5023820471 now and experience unmatched reliability and high performance in space-efficient connector solutions.
