MOLEX 874391400 Wire-to-Board Connector
The Pico-SPOX wire-to-board connector system features a 1.50mm pitch housing with a capacity of 14 circuits, designed for reliable electrical connections in compact applications. Made from flame-retardant nylon resin, it complies with UL and CSA standards and is RoHS and low-halogen compliant. The connector is stackable, polarized for secure mating, and operates within a temperature range of -55°C to +105°C. It supports a maximum current of 2.5A per contact, suitable for signal and low-power applications requiring durability and safety.
MOLEX 874391400 Wire-to-Board Connector Specifications:
- Pitch - Mating Interface: 1.50mm
- Circuits (maximum): 14
- Color - Resin: Off-White
- Flammability: 94V-0
- Material - Resin: Nylon
- Temperature Range - Operating: -55°C to +105°C
- Current - Maximum per Contact: 2.5A
- Stackable: Yes
- Polarized to Mating Part: Yes
- Lock to Mating Part: No
- Glow-Wire Capable: Yes
- Net Weight: 0.176g
- Packaging Type: Bag
- Application: Signal, Wire-to-Board
- Agency Certifications: UL, CSA
- RoHS and Low-Halogen compliant, Halogen-Free, REACH SVHC: Not Contained
Buy the Buy Molex Pico-SPOX Wire-to-Board Part Number 874391400 Online
Purchase the Molex Pico-SPOX wire-to-board connector online today to enhance your electronics assemblies with a high-quality, compact, and RoHS-compliant solution. Featuring 14 circuits with a 1.50mm pitch, this connector guarantees reliable electrical connections for signal and low-power applications. Its nylon housing is UL and CSA certified, flame-retardant, and stackable for versatile mounting options. Operating between -55°C and +105°C, supporting up to 2.5A per contact, it offers durability, safety, and ease of use for professional electronic projects and manufacturing processes.
Order your Molex Pico-SPOX 874391400 today and ensure your electronic projects benefit from safe, reliable, and compact wire-to-board connections with proven quality.
