MOLEX 877590814 Milli-Grid Header
The Milli-Grid Header is a surface mount, vertical connector with 8 circuits designed for high reliability and durability. It features 0.38-micrometer gold selective plating and is lead-free, suitable for board-to-board and signal applications. The connector supports up to 2A current per contact, operates in a temperature range of -55°C to +105°C, and meets UL and RoHS compliance standards. Made from black nylon with phosphor bronze contacts, it offers robust electrical performance and easy PCB retention for reliable connections in various electronic systems.
MOLEX 877590814 Milli-Grid Header Specifications:
- Number of Circuits: 8
- Color - Resin: Black
- Temperature Range - Operating: -55°C to +105°C
- Current - Maximum per Contact: 2.0A
- Voltage - Maximum: 125V
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Material - Resin: Nylon
- Flammability: 94V-0
- Plating min - Mating: 0.381μm
- Lock to Mating Part: None
- Mated Height: 3.80mm
- Orientation: Vertical
- Packaging Type: Tube
- Spacing - Mating Interface: 2.00mm
- Spacing - Termination Interface: 2.00mm
Buy the Molex Series Milli-Grid 8 Circuit Vertical Header: 877590814
Enhance your electronic assemblies with the reliable and durable Milli-Grid Header. Designed for surface mount applications, this 8-circuit connector features 0.38-micrometer gold selective plating, supporting up to 2A per contact. Its robust construction ensures operational stability from -55°C to +105°C, meeting UL and RoHS standards. Ideal for board-to-board and signal connections, this connector offers easy PCB retention, high durability, and compliance, making it the perfect choice for manufacturing high-quality electronic devices and systems.
Order your Molex Series Milli-Grid 8 Circuit Vertical Header today and give your projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy MOLEX 877590814?
You can click on the BUY or RFQ button to purchase 877590814 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 877590814?
You can download the 877590814 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 877590814?
MOLEX
