MOLEX 877591650 Connector System
The Milli-Grid Connector System features a surface-mount, vertical header with 16 circuits designed for reliable board-to-board connections in industrial electronics. Made from high-temperature thermoplastic with phosphor bronze contacts, it offers 2.0A current per contact, operating from -55°C to +125°C. Plated in gold and tin, it ensures excellent conductivity and corrosion resistance. Its compact 3.80mm pitch, RoHS compliance, and compatibility with Milli-Grid receptacles make it ideal for automation, control systems, and complex electronic assemblies requiring durable and precise connections.
MOLEX 877591650 Connector System Specifications:
- Number of Circuits: 16
- Pitch - Mating Interface: 2.00mm
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Material - Resin: High-Temperature Thermoplastic
- Temperature Range - Operating: -55°C to +125°C
- Current - Maximum per Contact: 2.0A
- Voltage - Maximum: 125V
- Dimensions - Mated Height: 0.381mm
- Color - Resin: Not specified
- Durability (mating cycles max): Not specified
- Flammability: Not specified
- RoHS compliance: Yes
- Halogen-Free: No
- PCB Retention: Not specified
- Packaging Type: Tube
- Certifications: UL Listed
- Process Temperature max.: 260°C
- Process Capability: Reflow, Max cycles 3
- Max. Process Time at Max Temperature: 10 seconds
Buy the Molex 877591650 – Reliable Surface Mount Connector for Industrial Applications
Purchase the Molex Milli-Grid Connector System online today to ensure high-quality, reliable connections for your industrial electronics. This surface-mount, vertical connector features 16 circuits, provides excellent conductivity with gold and tin plating, and is designed for durability with a temperature range from -55°C to +125°C. Its 3.80mm pitch and UL certification make it ideal for automation, control panels, and complex electronic assemblies requiring precise, long-lasting connections. Order now for fast delivery and superior performance.
Buy Molex 877591650 now and experience unmatched reliability and performance with its durable design and high-current capacity, perfect for complex industrial systems.
Frequently Asked Questions
Where can I buy MOLEX 877591650?
You can click on the BUY or RFQ button to purchase 877591650 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 877591650?
You can download the 877591650 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 877591650?
MOLEX
