NKK Switches JB15HAP1B Low Profile Tactile Switch
The JB15HAP1B is a low profile tactile switch designed for PCB applications, offering reliable tactile feedback and long operational life. It features a sealed construction with rubber seals to prevent contact contamination and allows automated soldering and cleaning, making it ideal for compact electronic devices. The switch has a crisp tactile response with a high cycle life of up to 5,000,000 operations, and the actuator's physical dimensions and materials ensure durability under various environmental conditions, including resistance to humidity, vibration, and shock. It supports low-voltage, low-current circuit operation with UL94V-0 rated plastics for safety.
NKK Switches JB15HAP1B Low Profile Tactile Switch Specifications:
- Electrical capacity: 50mA @ 24V DC (standard), 125mA @ 24V DC (high operating force)
- Contact resistance: 50 milliohms maximum
- Insulation resistance: 500 megohms minimum @ 250V DC
- Dielectric strength: 250V AC for 1 minute minimum
- Mechanical life: 5,000,000 operations minimum
- Electrical life: 5,000,000 operations minimum
- Operating force: 1.76N (standard), 2.65N (high)
- Total travel: 0.012" (0.30mm)
- Actuator: Polycarbonate, rubber seal
- Case: UL94V-0 rated plastic
- Seal: Rubber gasket
- Base: Glass fiber reinforced PBT
- Movable contacts material: Phosphor bronze with tin plating
- Stationary contacts material: Brass with silver plating
- Terminals: Slanted molded-in for secure mounting
- Environmental conditions: Operating temperature from 25°C to +70°C, humidity 90-95%, vibration and shock resistant, IP67 sealing
- Soldering: Wave, manual, and automated cleaning compatible
