NKK Switches LB16WKW01CJ Panel Seal Switch
This is a versatile single-pole double-throw panel switch with a round black housing, designed for reliable circuit control. It features a red lens with a clear filter, compatible with incandescent lamps and nonilluminated applications. Rated for 3A at 125V/250V AC and 0.4VA at 28V AC/DC, the switch offers durability with snap-action contacts, IP65 sealing, and quick connect terminals. Its compact design minimizes behind-panel depth, suitable for industrial control panels, with options for illumination and custom legends for enhanced visibility and operation.
NKK Switches LB16WKW01CJ Panel Seal Switch Specifications:
- Housing Color: Black
- Contact Materials: Silver or Gold-plated
- Rating: 3A @ 125/250V AC, 0.4VA @ 28V AC/DC
- Electrical Resistance: 50 milliohms maximum for silver contacts
- Insulation Resistance: 200 megohms minimum @ 500V DC
- Dielectric Strength: 1,000V AC between contacts for 1 min
- Mechanical Life: 1,000,000 operations minimum
- Electrical Life: 200,000 operations minimum
- Travel: Total 0.118” (3.0mm)
- Pretravel & Overtravel: 0.059” (1.5mm)
- Mounting: Front panel, recommended panel thickness 0.039” to 0.157”
- Sealing: IP65 (IEC60529), similar to NEMA 4 & 13
- Operating Temperature Range: -25°C to +50°C
- Vibration & Shock Resistance: 10~55Hz, 50G acceleration
- Mounting Torque: 1.96Nm (17.35 lbs-in)
Buy the NKK Series LB Panel Seal Pushbutton Switch: LB16WKW01CJ
Order the NKK Series LB16WKW01CJ panel seal switch online today and enjoy guaranteed durability, IP65 sealing for harsh environments, quick connect terminals for easy installation, and versatile lighting options including LED illumination. Its compact design fits easily behind panels and provides long-lasting operation, ideal for industrial controls, automation, and panel assemblies. Make your purchase now and ensure reliable circuit control with this durable, high-quality switch designed for demanding applications.
Buy NKK Series LB16WKW01CJ panel seal pushbutton switch now and experience unmatched reliability and performance in industrial control applications.
Frequently Asked Questions
Where can I buy NKK Switches LB16WKW01CJ?
You can click on the BUY or RFQ button to purchase LB16WKW01CJ from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part LB16WKW01CJ?
You can download the LB16WKW01CJ datasheet or visit the NKK Switches website for support.
Who is the manufacturer of LB16WKW01CJ?
NKK Switches
