NKK Switches YB215CWSKW01NFB Sealed Toggle Switch
This is a highly reliable, single-pole double-throw toggle switch designed for industrial control panels. It features on-on switching action with a durable black panel seal bezel for splashproof and dust-tight operation meeting IP65 standards. Capable of handling 3A at 125V AC, it includes solder lug and quick connect terminals, ensuring secure and flexible wiring. Suitable for automation and machinery applications, it offers crisp actuation, long mechanical life, and easy installation, making it ideal for industrial environments requiring robust, sealed toggles with customizable legends and clear circuit status indication.
NKK Switches YB215CWSKW01NFB Sealed Toggle Switch Specifications:
- Poles & Circuits: Single Pole Double Throw (SPDT)
- Contact rating: 3A at 125V AC
- Terminals: Solder Lug and 0.110" quick connect
- Housing: Black, water and dust resistant with IP65 sealing
- Switch action: ON-ON with crisp tactile response
- Mechanical life: 1,000,000 operations
- Electrical life: 200,000 operations
- Mounting torque: 0.785Nm (6.95 Ibf-in) maximum
- Operating temperature: -25°C to +50°C
- Dimensional size: 19.0mm diameter, with square bezel
- Certifications: Meets IEC60529 IP65 standard
Buy the NKK YB2 – Reliable Toggle Switch for Industrial Applications
Purchase your NKK YB2 series sealed toggle switch online today and enhance the reliability of your control systems. With IP65 sealing, 3A current capacity, and flexible terminal options, this switch is ideal for industrial automation and control panel applications. Its durable design ensures long-term operation under harsh conditions, while easy installation and crisp actuation improve your workflow. Don't compromise on quality—order now to get a dependable, splashproof toggle switch with customizable legends and clear circuit indication delivered promptly to your project site.
Order your NKK YB2 switch today and ensure your control panels are sealed, reliable, and easy to operate in demanding industrial environments.
Frequently Asked Questions
Where can I buy NKK Switches YB215CWSKW01NFB?
You can click on the BUY or RFQ button to purchase YB215CWSKW01NFB from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part YB215CWSKW01NFB?
You can download the YB215CWSKW01NFB datasheet or visit the NKK Switches website for support.
Who is the manufacturer of YB215CWSKW01NFB?
NKK Switches
