OMEGA CN7263 Process Control Module
The CN7263 is a dual output process controller featuring 0 to 5V and 0 to 10V linear voltage outputs, suitable for precise voltage control in industrial automation. It supports various input types including thermocouples, RTDs, and voltage or current signals, with high accuracy of +0.25% span. Its dual LED displays provide clear process and setpoint readings, while its RS485 MODBUS communication ensures easy integration. This compact, IP66-rated device operates from 100-240 Vac, with durable construction and configurable alarm outputs, making it ideal for demanding control applications.
OMEGA CN7263 Process Control Module Specifications:
- Inputs: Thermocouple, RTD, DC voltages, or DC current
- Display: Dual 4-digit, 7-segment; PV: Red, 19 mm (0.75"), SV: Green, 12.7 mm (0.5")
- Accuracy: +0.25% span, +1 least significant digit
- Supply Voltage: 100 to 240 Vac, 50/60 Hz
- Power Consumption: 5 VA maximum
- Operating Temperature: 0 to 50°C (32 to 122°F)
- Memory Backup: Nonvolatile memory
- Control Output Ratings: Relay SPDT 5A @ 250 Vac, Voltage Pulse 14V 10 to -20%, Max 40 mA, Current 4-20 mA, Linear Voltage 0-5V & 0-10V
- Communication: RS485 MODBUS RTU protocol
- Panel Cutout: 92 mm, Dimensions: 96 x 96 x 15.8 mm, Panel Depth: 79.2 mm, Weight: 425 g
- Front Panel Rating: IP66
- Input Ranges: Thermocouples Type K, J, T, E, N, R, S, L, U, and RTD Pt 100, Voltage 0-50 mV, 0-5V, 0-10V, 0-20mA, 4-20mA
- Additional Accessories and options available for different output configurations
Buy the Buy Averr CN7263 Part Number CN7263 Online
Secure your Averr CN7263 dual voltage output process controller online today. Its versatile input options including thermocouples and RTDs, combined with high accuracy and dual voltage outputs, make it ideal for precise industrial temperature and process control. Featuring dual LED displays for clear monitoring and RS485 MODBUS communication, this compact IP66-rated device seamlessly integrates into automation systems. Trust in its durable design and extensive configuration options to ensure your control processes are efficient, reliable, and easily manageable from any location.
Order your Averr CN7263 dual voltage process controller today and enhance your industrial automation projects with reliable control and communication features.
Frequently Asked Questions
Where can I buy OMEGA CN7263?
You can click on the BUY or RFQ button to purchase CN7263 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part CN7263?
You can download the CN7263 datasheet or visit the OMEGA website for support.
Who is the manufacturer of CN7263?
OMEGA
