OMEGA CN7553 Process Controller
The CN7200 series temperature and process controllers feature dual 4-digit LED displays, supporting thermocouple, RTD, voltage, or current inputs for precise temperature control. They offer extensive programming options including ON/OFF, PID, autotune, and manual tuning, with up to 64 ramp/soak sequences. Equipped with dual control outputs, alarm functions, RS485 communication, and nonvolatile memory backup, these units are suitable for industrial temperature management. The controllers have a compact design, IP66-rated front panel, and versatile input and output configurations for complex process automation.
OMEGA CN7553 Process Controller Specifications:
- Inputs: Thermocouple (Type J, K, T, E, N, R, S, L, U, etc.), RTD, DC voltages or DC current
- Display: Two 4-digit, 7-segment LED PV: Red, 19 mm (0.75") H, SV: Green, 12.7 mm (0.5") H
- Accuracy: +0.25% span, +1 least significant digit
- Supply Voltage: 100 to 240 Vac, 50/60 Hz
- Power Consumption: 5 VA maximum
- Operating Temperature: 0 to 50°C (32 to 122°F)
- Memory Backup: Nonvolatile memory
- Control Output Ratings: Relay SPDT 5A @ 250 Vac resistive, Voltage pulse 14V, 10 to -20% (max 40 mA), 4 to 20 mA, 0-5V, 0-10V
- Communication: RS485 MODBUS RTU protocol
- Panel Cutout: 92 mm (3.622")
- Dimensions: 96 x 96 x 15.8 mm bezel, Panel Depth: 79.2 mm (3.125")
- Weight: 425 g (15 oz), Front Panel Rating: IP66
- Input Types Range: Thermocouples from -200°C to 1800°C, RTD -200°C to 600°C, Voltages -999 to 9999 units, 4-20 mA -999 to 9999 units
Buy the Omega CN7200 – Reliable Process Controllers for Industrial Applications
Upgrade your industrial temperature management with the Omega CN7200 series process controllers. Featuring dual 4-digit LED displays, multiple input options such as thermocouples and RTDs, and programmable controls including PID and autotuning. Equipped with dual control outputs and alarm functions, these controllers ensure precise process regulation. The units support RS485 communication for seamless integration into automation systems. Compact, IP66 rated front panel, and nonvolatile memory backup make the CN7200 series ideal for demanding industrial environments. Purchase online today for reliable, efficient control.
Buy Omega CN7200 now and experience unmatched reliability and performance in temperature control systems with versatile input options and robust communication features.
Frequently Asked Questions
Where can I buy OMEGA CN7553?
You can click on the BUY or RFQ button to purchase CN7553 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part CN7553?
You can download the CN7553 datasheet or visit the OMEGA website for support.
Who is the manufacturer of CN7553?
OMEGA
